| 编号 | 芯数 X 标称截面mm² | 绝缘厚度mm | 护套厚度mm | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 1X1.5mm² | 0.8 | 0.8 | 5.3 | 23 | 51 |
| 2 | 1X2.5mm² | 1.0 | 1.0 | 6.6 | 35 | 79 |
| 3 | 1X4.0mm² | 1.0 | 1.1 | 7.3 | 53 | 106 |
| 4 | 1X6.0mm² | 1.0 | 1.1 | 8.1 | 74 | 133 |
| 5 | 1X10mm² | 1.0 | 1.3 | 9.5 | 114 | 193 |
| 6 | 1X16mm² | 1.1 | 1.3 | 10.9 | 173 | 272 |
| 7 | 1X25mm² | 1.3 | 1.5 | 13.2 | 262 | 403 |
| 8 | 1X35mm² | 1.3 | 1.5 | 14.6 | 358 | 519 |
| 9 | 1X50mm² | 1.5 | 1.7 | 17.0 | 503 | 716 |
| 10 | 1X70mm² | 1.5 | 1.7 | 19.0 | 709 | 953 |
| 11 | 1X95mm² | 1.5 | 1.7 | 21.0 | 947 | 1223 |
| 12 | 1X120mm² | 1.5 | 1.7 | 22.7 | 1182 | 1485 |
| 13 | 1X150mm² | 1.8 | 2.0 | 25.7 | 1469 | 1873 |
| 14 | 1X185mm² | 2.0 | 2.2 | 28.5 | 1800 | 2295 |
| 15 | 1X240mm² | 2.2 | 2.4 | 32.0 | 2319 | 2929 |
