| 物料编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 2X0.5mm² | 5.5 | 9.5 | 36 | |
| 3G0.5mm² | 5.8 | 14.2 | 45 | |
| 4G0.5mm² | 6.2 | 19.0 | 54 | |
| 5G0.5mm² | 6.8 | 23.7 | 65 | |
| 6G0.5mm² | 7.5 | 28.5 | 79 | |
| 7G0.5mm² | 8.0 | 33.2 | 90 | |
| 8G0.5mm² | 8.8 | 38.0 | 106 | |
| 10G0.5mm² | 9.7 | 47.5 | 127 | |
| 12G0.5mm² | 10.0 | 57.0 | 144 | |
| 14G0.5mm² | 10.7 | 66.4 | 167 | |
| 15G0.5mm² | 11.1 | 71.2 | 182 | |
| 16G0.5mm² | 11.4 | 75.9 | 190 | |
| 18G0.5mm² | 12.1 | 85.4 | 219 | |
| 20G0.5mm² | 12.6 | 94.9 | 236 | |
| 24G0.5mm² | 14.1 | 113.9 | 285 | |
| 25G0.5mm² | 14.1 | 118.7 | 298 | |
| 30G0.5mm² | 14.8 | 142.4 | 355 | |
| 36G0.5mm² | 16.1 | 170.9 | 422 | |
| 2X0.75mm² | 5.9 | 14.1 | 43 | |
| 3G0.75mm² | 6.2 | 21.1 | 55 | |
| 4G0.75mm² | 6.9 | 28.2 | 71 | |
| 5G0.75mm² | 7.5 | 35.2 | 85 | |
| 6G0.75mm² | 8.3 | 42.3 | 103 | |
| 7G0.75mm² | 8.9 | 49.3 | 118 | |
| 8G0.75mm² | 9.8 | 56.4 | 146 | |
| 10G0.75mm² | 10.7 | 70.4 | 165 | |
| 12G0.75mm² | 11.0 | 84.5 | 188 | |
| 14G0.75mm² | 11.5 | 98.6 | 212 | |
| 15G0.75mm² | 12.0 | 105.7 | 230 | |
| 16G0.75mm² | 12.5 | 112.7 | 247 | |
| 18G0.75mm² | 13.1 | 126.8 | 277 | |
| 20G0.75mm² | 13.7 | 140.9 | 309 | |
| 24G0.75mm² | 15.3 | 169.1 | 379 | |
| 25G0.75mm² | 15.3 | 176.1 | 379 | |
| 30G0.75mm² | 16.3 | 211.3 | 462 | |
| 36G0.75mm² | 17.7 | 253.6 | 549 | |
| 2X1.0mm² | 6.7 | 18.8 | 56 | |
| 3G1.0mm² | 7.0 | 28.3 | 71 | |
| 4G1.0mm² | 7.6 | 37.7 | 88 | |
| 5G1.0mm² | 8.5 | 47.1 | 110 | |
| 6G1.0mm² | 9.4 | 56.5 | 133 | |
| 7G1.0mm² | 10.1 | 65.9 | 152 | |
| 8G1.0mm² | 11.0 | 75.3 | 189 | |
| 10G1.0mm² | 12.1 | 94.2 | 213 | |
| 12G1.0mm² | 12.7 | 113.0 | 249 | |
| 14G1.0mm² | 13.3 | 131.9 | 281 | |
| 15G1.0mm² | 13.8 | 141.3 | 305 | |
| 16G1.0mm² | 14.1 | 150.7 | 319 | |
| 18G1.0mm² | 14.8 | 169.5 | 359 | |
| 20G1.0mm² | 15.7 | 188.4 | 408 | |
| 24G1.0mm² | 17.3 | 226.0 | 491 | |
| 25G1.0mm² | 17.3 | 235.5 | 478 | |
| 30G1.0mm² | 18.5 | 282.5 | 571 | |
| 36G1.0mm² | 19.8 | 339.0 | 669 | |
| 2X1.5mm² | 7.7 | 28.3 | 74 | |
| 3G1.5mm² | 8.1 | 42.5 | 97 | |
| 4G1.5mm² | 9.0 | 56.7 | 125 | |
| 5G1.5mm² | 10.1 | 70.8 | 156 | |
| 6G1.5mm² | 11.1 | 85.0 | 189 | |
| 7G1.5mm² | 12.1 | 99.1 | 223 | |
| 8G1.5mm² | 13.3 | 113.3 | 275 | |
| 10G1.5mm² | 14.3 | 141.6 | 302 | |
| 12G1.5mm² | 14.9 | 170.0 | 354 | |
| 14G1.5mm² | 15.9 | 198.3 | 408 | |
| 15G1.5mm² | 16.2 | 212.5 | 434 | |
| 16G1.5mm² | 16.7 | 226.6 | 454 | |
| 18G1.5mm² | 17.7 | 255.0 | 521 | |
| 20G1.5mm² | 18.6 | 283.3 | 583 | |
| 24G1.5mm² | 20.9 | 339.9 | 724 | |
| 25G1.5mm² | 20.9 | 354.1 | 724 | |
| 30G1.5mm² | 22.1 | 424.9 | 871 | |
| 36G1.5mm² | 24.3 | 509.9 | 1058 | |
| 2X2.5mm² | 9.5 | 47.2 | 116 | |
| 3G2.5mm² | 10.0 | 70.7 | 152 | |
| 4G2.5mm² | 11.1 | 94.3 | 195 | |
| 5G2.5mm² | 12.4 | 117.9 | 243 | |
| 6G2.5mm² | 13.6 | 141.5 | 293 | |
| 7G2.5mm² | 14.9 | 165.1 | 360 | |
| 8G2.5mm² | 16.2 | 188.7 | 425 | |
| 10G2.5mm² | 17.7 | 235.8 | 477 | |
| 12G2.5mm² | 18.2 | 283.0 | 549 | |
| 14G2.5mm² | 19.2 | 330.1 | 623 | |
| 15G2.5mm² | 19.6 | 353.7 | 664 | |
| 16G2.5mm² | 20.6 | 377.3 | 716 | |
| 18G2.5mm² | 21.6 | 424.5 | 809 | |
| 20G2.5mm² | 23.1 | 471.6 | 928 | |
| 24G2.5mm² | 25.9 | 566.0 | 1147 | |
| 25G2.5mm² | 25.9 | 589.6 | 1149 |
