应用范围：
| 编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 2X0.14mm² | 6.6 | 26.5 | 57 |
| 2 | 3X0.14mm² | 6.9 | 33.6 | 69 |
| 3 | 4X0.14mm² | 7.5 | 41.3 | 83 |
| 4 | 5X0.14mm² | 8.3 | 49.3 | 101 |
| 5 | 6X0.14mm² | 9.1 | 57.3 | 120 |
| 6 | 7X0.14mm² | 9.1 | 63.3 | 129 |
| 7 | 8X0.14mm² | 9.7 | 71.4 | 144 |
| 8 | 2X0.25mm² | 7.0 | 29.7 | 64 |
| 9 | 3X0.25mm² | 7.6 | 37.7 | 81 |
| 10 | 4X0.25mm² | 8.2 | 46.5 | 97 |
| 11 | 5X0.25mm² | 9.0 | 55.6 | 117 |
| 12 | 6X0.25mm² | 9.7 | 64.7 | 134 |
| 13 | 7X0.25mm² | 9.7 | 71.6 | 146 |
| 14 | 8X0.25mm² | 10.6 | 80.7 | 168 |
| 15 | 2X0.34mm² | 7.4 | 34.3 | 73 |
| 16 | 3X0.34mm² | 7.8 | 44.4 | 90 |
| 17 | 4X0.34mm² | 8.6 | 55.4 | 112 |
| 18 | 5X0.34mm² | 9.3 | 66.5 | 131 |
| 19 | 6X0.34mm² | 10.2 | 77.7 | 155 |
| 20 | 7X0.34mm² | 10.2 | 86.6 | 169 |
| 21 | 8X0.34mm² | 10.9 | 97.9 | 189 |
