应用范围：
| 物料编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 2X2X0.22mm² | 7.5 | 28.5 | 67 | |
| 3X2X0.22mm² | 7.9 | 36.1 | 80 | |
| 4X2X0.22mm² | 8.7 | 44.3 | 99 | |
| 5X2X0.22mm² | 9.4 | 52.7 | 114 | |
| 6X2X0.22mm² | 10.3 | 61.2 | 134 | |
| 8X2X0.22mm² | 11.0 | 76.0 | 160 | |
| 10X2X0.22mm² | 12.9 | 93.7 | 200 | |
| 2X2X0.34mm² | 7.8 | 36.6 | 77 | |
| 3X2X0.34mm² | 8.3 | 47.7 | 94 | |
| 4X2X0.34mm² | 9.2 | 59.5 | 117 | |
| 5X2X0.34mm² | 10.1 | 71.5 | 141 | |
| 6X2X0.34mm² | 10.8 | 83.7 | 161 | |
| 8X2X0.34mm² | 11.8 | 105.5 | 200 | |
| 10X2X0.34mm² | 13.6 | 130.5 | 243 | |
| 2X2X0.5mm² | 8.6 | 48.0 | 94 | |
| 3X2X0.5mm² | 9.3 | 63.8 | 121 | |
| 4X2X0.5mm² | 10.2 | 80.5 | 150 | |
| 5X2X0.5mm² | 11.3 | 97.3 | 181 | |
| 6X2X0.5mm² | 12.1 | 86.1 | 171 | |
| 8X2X0.5mm² | 13.0 | 145.5 | 254 | |
| 10X2X0.5mm² | 15.4 | 180.5 | 324 | |
| 2X2X0.75mm² | 9.5 | 60.2 | 115 | |
| 3X2X0.75mm² | 10.3 | 81.1 | 149 | |
| 4X2X0.75mm² | 11.3 | 102.9 | 186 | |
| 2X2X1.0mm² | 11.0 | 73.2 | 147 | |
| 3X2X1.0mm² | 11.6 | 99.2 | 184 | |
| 4X2X1.0mm² | 12.6 | 126.3 | 223 |
