| 物料编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1X2X0.14mm² | 4.3 | 8.8 | 24 | |
| 2X2X0.14mm² | 5.8 | 14.7 | 40 | |
| 3X2X0.14mm² | 6.4 | 18.4 | 50 | |
| 4X2X0.14mm² | 6.9 | 22.3 | 59 | |
| 5X2X0.14mm² | 7.4 | 26.3 | 67 | |
| 6X2X0.14mm² | 7.9 | 27.8 | 69 | |
| 7X2X0.14mm² | 7.9 | 30.6 | 74 | |
| 8X2X0.14mm² | 8.7 | 40.4 | 98 | |
| 10X2X0.14mm² | 10.2 | 49.6 | 123 | |
| 12X2X0.14mm² | 10.6 | 55.9 | 140 | |
| 16X2X0.14mm² | 11.8 | 69.8 | 175 | |
| 20X2X0.14mm² | 12.9 | 84.0 | 205 | |
| 25X2X0.14mm² | 14.4 | 101.4 | 249 | |
| 1X2X0.25mm² | 4.7 | 11.5 | 29 | |
| 2X2X0.25mm² | 6.5 | 19.9 | 49 | |
| 3X2X0.25mm² | 7.1 | 25.5 | 63 | |
| 4X2X0.25mm² | 7.7 | 34.2 | 78 | |
| 5X2X0.25mm² | 8.5 | 40.6 | 94 | |
| 6X2X0.25mm² | 9.3 | 47.0 | 111 | |
| 7X2X0.25mm² | 9.3 | 51.6 | 119 | |
| 8X2X0.25mm² | 10.2 | 58.0 | 136 | |
| 10X2X0.25mm² | 11.7 | 71.5 | 165 | |
| 12X2X0.25mm² | 12.2 | 81.6 | 189 | |
| 16X2X0.25mm² | 11.4 | 103.2 | 175 | |
| 20X2X0.25mm² | 14.9 | 125.2 | 281 | |
| 25X2X0.25mm² | 16.6 | 152.3 | 342 | |
| 1X2X0.34mm² | 4.9 | 13.6 | 32 | |
| 2X2X0.34mm² | 7.0 | 23.9 | 58 | |
| 3X2X0.34mm² | 7.5 | 34.0 | 74 | |
| 4X2X0.34mm² | 8.1 | 41.9 | 89 | |
| 5X2X0.34mm² | 8.9 | 50.0 | 107 | |
| 6X2X0.34mm² | 9.8 | 58.2 | 127 | |
| 7X2X0.34mm² | 9.8 | 64.4 | 137 | |
| 8X2X0.34mm² | 10.7 | 72.6 | 157 | |
| 10X2X0.34mm² | 12.5 | 89.7 | 197 | |
| 12X2X0.34mm² | 12.9 | 103.1 | 220 | |
| 16X2X0.34mm² | 14.4 | 131.4 | 277 | |
| 1X2X0.5mm² | 5.3 | 17.5 | 38 | |
| 2X2X0.5mm² | 7.6 | 34.1 | 73 | |
| 3X2X0.5mm² | 8.2 | 44.8 | 91 | |
| 4X2X0.5mm² | 9.1 | 55.9 | 114 | |
| 5X2X0.5mm² | 10.0 | 67.2 | 138 | |
| 6X2X0.5mm² | 11.0 | 60.5 | 136 | |
| 7X2X0.5mm² | 11.0 | 69.6 | 150 | |
| 8X2X0.5mm² | 12.0 | 99.2 | 203 | |
| 10X2X0.5mm² | 14.1 | 122.8 | 254 | |
| 12X2X0.5mm² | 14.5 | 142.1 | 285 | |
| 16X2X0.5mm² | 16.1 | 182.7 | 361 | |
| 1X2X0.75mm² | 5.9 | 23.2 | 49 | |
| 2X2X0.75mm² | 8.3 | 45.5 | 89 | |
| 3X2X0.75mm² | 9.1 | 61.2 | 117 | |
| 4X2X0.75mm² | 10.1 | 77.3 | 147 | |
| 5X2X0.75mm² | 11.1 | 93.6 | 179 | |
| 6X2X0.75mm² | 12.2 | 110.1 | 211 | |
| 1X2X1.0mm² | 6.5 | 29.3 | 60 | |
| 2X2X1.0mm² | 9.6 | 57.5 | 118 | |
| 3X2X1.0mm² | 10.6 | 78.2 | 155 | |
| 4X2X1.0mm² | 11.5 | 99.3 | 189 |
