| 物料编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1X2X0.14mm² | 3.8 | 2.8 | 16 | |
| 2X2X0.14mm² | 5.1 | 5.7 | 26 | |
| 3X2X0.14mm² | 5.5 | 8.5 | 33 | |
| 4X2X0.14mm² | 6.2 | 11.4 | 43 | |
| 5X2X0.14mm² | 6.7 | 14.2 | 50 | |
| 8X2X0.14mm² | 8.0 | 22.8 | 74 | |
| 1X2X0.25mm² | 4.2 | 4.7 | 20 | |
| 2X2X0.25mm² | 6.0 | 9.4 | 37 | |
| 3X2X0.25mm² | 6.4 | 14.2 | 46 | |
| 4X2X0.25mm² | 7.0 | 18.9 | 57 | |
| 5X2X0.25mm² | 7.6 | 23.6 | 67 | |
| 6X2X0.25mm² | 8.4 | 28.3 | 82 | |
| 7X2X0.25mm² | 8.4 | 33.1 | 90 | |
| 8X2X0.25mm² | 9.3 | 37.8 | 105 | |
| 10X2X0.25mm² | 11.0 | 47.2 | 133 | |
| 1X2X0.34mm² | 4.4 | 6.4 | 23 | |
| 2X2X0.34mm² | 6.3 | 12.8 | 42 | |
| 3X2X0.34mm² | 6.8 | 19.2 | 54 | |
| 4X2X0.34mm² | 7.4 | 25.6 | 67 | |
| 5X2X0.34mm² | 8.2 | 32.1 | 83 | |
| 6X2X0.34mm² | 8.9 | 38.5 | 96 | |
| 7X2X0.34mm² | 8.9 | 44.9 | 106 | |
| 8X2X0.34mm² | 9.8 | 51.3 | 124 | |
| 10X2X0.34mm² | 11.8 | 64.1 | 162 | |
| 1X2X0.5mm² | 4.8 | 9.4 | 29 | |
| 2X2X0.5mm² | 6.9 | 18.9 | 53 | |
| 3X2X0.5mm² | 7.5 | 28.3 | 69 | |
| 4X2X0.5mm² | 8.4 | 37.8 | 90 | |
| 5X2X0.5mm² | 9.3 | 47.2 | 111 |
