应用范围：
| 编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 1X2X0.14mm² | 4.3 | 8.8 | 24 |
| 2 | 2X2X0.14mm² | 5.8 | 14.7 | 40 |
| 3 | 3X2X0.14mm² | 6.4 | 18.4 | 50 |
| 4 | 4X2X0.14mm² | 6.9 | 22.3 | 59 |
| 5 | 5X2X0.14mm² | 7.4 | 26.3 | 67 |
| 6 | 6X2X0.14mm² | 7.9 | 27.8 | 69 |
| 7 | 7X2X0.14mm² | 7.9 | 30.6 | 74 |
| 8 | 8X2X0.14mm² | 8.7 | 40.4 | 98 |
| 9 | 10X2X0.14mm² | 10.2 | 49.6 | 123 |
| 10 | 12X2X0.14mm² | 10.6 | 55.9 | 140 |
| 11 | 16X2X0.14mm² | 11.8 | 69.8 | 175 |
| 12 | 20X2X0.14mm² | 12.9 | 84.0 | 205 |
| 13 | 25X2X0.14mm² | 14.4 | 101.4 | 249 |
| 14 | 1X2X0.25mm² | 4.7 | 11.5 | 29 |
| 15 | 2X2X0.25mm² | 6.5 | 19.9 | 49 |
| 16 | 3X2X0.25mm² | 7.1 | 25.5 | 63 |
| 17 | 4X2X0.25mm² | 7.7 | 34.2 | 78 |
| 18 | 5X2X0.25mm² | 8.5 | 40.6 | 94 |
| 19 | 6X2X0.25mm² | 9.3 | 47.0 | 111 |
| 20 | 7X2X0.25mm² | 9.3 | 51.6 | 119 |
| 21 | 8X2X0.25mm² | 10.2 | 58.0 | 136 |
| 22 | 10X2X0.25mm² | 11.7 | 71.5 | 165 |
| 23 | 12X2X0.25mm² | 12.2 | 81.6 | 189 |
| 24 | 16X2X0.25mm² | 11.4 | 103.2 | 175 |
| 25 | 20X2X0.25mm² | 14.9 | 125.2 | 281 |
| 26 | 25X2X0.25mm² | 16.6 | 152.3 | 342 |
| 27 | 1X2X0.34mm² | 4.9 | 13.6 | 32 |
| 28 | 2X2X0.34mm² | 7.0 | 23.9 | 58 |
| 29 | 3X2X0.34mm² | 7.5 | 34.0 | 74 |
| 30 | 4X2X0.34mm² | 8.1 | 41.9 | 89 |
| 31 | 5X2X0.34mm² | 8.9 | 50.0 | 107 |
| 32 | 6X2X0.34mm² | 9.8 | 58.2 | 127 |
| 33 | 7X2X0.34mm² | 9.8 | 64.4 | 137 |
| 34 | 8X2X0.34mm² | 10.7 | 72.6 | 157 |
| 35 | 10X2X0.34mm² | 12.5 | 89.7 | 197 |
| 36 | 12X2X0.34mm² | 12.9 | 103.1 | 220 |
| 37 | 16X2X0.34mm² | 14.4 | 131.4 | 277 |
| 38 | 1X2X0.5mm² | 5.3 | 17.5 | 38 |
| 39 | 2X2X0.5mm² | 7.6 | 34.1 | 73 |
| 40 | 3X2X0.5mm² | 8.2 | 44.8 | 91 |
| 41 | 4X2X0.5mm² | 9.1 | 55.9 | 114 |
| 42 | 5X2X0.5mm² | 10.0 | 67.2 | 138 |
| 43 | 6X2X0.5mm² | 11.0 | 60.5 | 136 |
| 44 | 7X2X0.5mm² | 11.0 | 69.6 | 150 |
| 45 | 8X2X0.5mm² | 12.0 | 99.2 | 203 |
| 46 | 10X2X0.5mm² | 14.1 | 122.8 | 254 |
| 47 | 12X2X0.5mm² | 14.5 | 142.1 | 285 |
| 48 | 16X2X0.5mm² | 16.1 | 182.7 | 361 |
| 49 | 1X2X0.75mm² | 5.9 | 23.2 | 49 |
| 50 | 2X2X0.75mm² | 8.3 | 45.5 | 89 |
| 51 | 3X2X0.75mm² | 9.1 | 61.2 | 117 |
| 52 | 4X2X0.75mm² | 10.1 | 77.3 | 147 |
| 53 | 5X2X0.75mm² | 11.1 | 93.6 | 179 |
| 54 | 6X2X0.75mm² | 12.2 | 110.1 | 211 |
| 55 | 1X2X1.0mm² | 6.5 | 29.3 | 60 |
| 56 | 2X2X1.0mm² | 9.6 | 57.5 | 118 |
| 57 | 3X2X1.0mm² | 10.6 | 78.2 | 155 |
| 58 | 4X2X1.0mm² | 11.5 | 99.3 | 189 |
