应用范围：
| 编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 2X4.0mm² | 12.5 | 74 | 192 |
| 2 | 3G4.0mm² | 13.5 | 111 | 261 |
| 3 | 4G4.0mm² | 14.7 | 148 | 329 |
| 4 | 5G4.0mm² | 16.3 | 184 | 405 |
| 5 | 2X6.0mm² | 14.4 | 110 | 261 |
| 6 | 3G6.0mm² | 15.3 | 165 | 351 |
| 7 | 4G6.0mm² | 16.9 | 220 | 452 |
| 8 | 5G6.0mm² | 18.7 | 274 | 558 |
| 9 | 2X10mm² | 16.6 | 184 | 376 |
| 10 | 3G10mm² | 17.8 | 275 | 519 |
| 11 | 4G10mm² | 19.7 | 367 | 671 |
| 12 | 5G10mm² | 22.0 | 459 | 837 |
| 13 | 2X16mm² | 19.3 | 293 | 544 |
| 14 | 3G16mm² | 20.6 | 440 | 749 |
| 15 | 4G16mm² | 23.0 | 587 | 982 |
| 16 | 5G16mm² | 25.6 | 733 | 1222 |
| 17 | 2X25mm² | 23.7 | 459 | 833 |
| 18 | 3G25mm² | 25.3 | 688 | 1149 |
| 19 | 4G25mm² | 28.1 | 918 | 1502 |
| 20 | 5G25mm² | 31.3 | 1147 | 1865 |
| 21 | 2X35mm² | 26.9 | 642 | 1109 |
| 22 | 3G35mm² | 28.7 | 963 | 1538 |
| 23 | 4G35mm² | 31.9 | 1283 | 2011 |
| 24 | 5G35mm² | 35.8 | 1604 | 2526 |
| 25 | 2X50mm² | 31.8 | 916 | 1562 |
| 26 | 3G50mm² | 33.9 | 1374 | 2171 |
| 27 | 4G50mm² | 38.0 | 1832 | 2865 |
| 28 | 5G50mm² | 42.1 | 2290 | 3549 |
| 29 | 2X70mm² | 35.9 | 1283 | 2078 |
| 30 | 3G70mm² | 38.6 | 1925 | 2938 |
| 31 | 4G70mm² | 43.2 | 2567 | 3869 |
| 32 | 5G70mm² | 47.9 | 3208 | 4790 |
| 33 | 2X95mm² | 41.5 | 1741 | 2795 |
| 34 | 3G95mm² | 44.6 | 2612 | 3952 |
| 35 | 4G95mm² | 49.4 | 3483 | 5155 |
| 36 | 5G95mm² | 54.8 | 4354 | 6385 |
| 37 | 2X120mm² | 45.3 | 2200 | 3429 |
| 38 | 3G120mm² | 48.8 | 3299 | 4860 |
| 39 | 4G120mm² | 54.0 | 4399 | 6346 |
| 40 | 5G120mm² | 59.8 | 5499 | 7863 |
| 41 | 2X150mm² | 50.2 | 2749 | 4236 |
| 42 | 3G150mm² | 54.0 | 4123 | 6015 |
| 43 | 4G150mm² | 59.8 | 5497 | 7860 |
| 44 | 5G150mm² | 66.5 | 6871 | 9769 |
| 45 | 2X185mm² | 55.2 | 3387 | 5164 |
| 46 | 3G185mm² | 59.4 | 5080 | 7346 |
| 47 | 4G185mm² | 66.0 | 6774 | 9632 |
| 48 | 5G185mm² | 73.3 | 8467 | 11968 |
| 49 | 2X240mm² | 62.4 | 4389 | 6642 |
| 50 | 3G240mm² | 66.7 | 6583 | 9393 |
| 51 | 4G240mm² | 74.0 | 8778 | 12320 |
| 52 | 5G240mm² | 82.0 | 10972 | 15273 |
