应用范围：
| 编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 2X1.5mm² | 9.7 | 28 | 136 |
| 3G1.5mm² | 10.2 | 41 | 159 | |
| 4G1.5mm² | 10.9 | 55 | 189 | |
| 5G1.5mm² | 11.8 | 69 | 224 | |
| 6G1.5mm² | 12.7 | 83 | 262 | |
| 7G1.5mm² | 12.7 | 97 | 274 | |
| 8G1.5mm² | 13.6 | 111 | 285 | |
| 10G1.5mm² | 15.7 | 138 | 360 | |
| 12G1.5mm² | 16.2 | 166 | 408 | |
| 19G1.5mm² | 18.7 | 263 | 588 | |
| 25G1.5mm² | 22.1 | 346 | 780 | |
| 30G1.5mm² | 23.3 | 415 | 904 | |
| 37G1.5mm² | 25.5 | 511 | 1103 | |
| 2X2.5mm² | 10.7 | 46 | 175 | |
| 3G2.5mm² | 11.3 | 69 | 209 | |
| 4G2.5mm² | 12.1 | 92 | 253 | |
| 5G2.5mm² | 13.2 | 115 | 303 | |
| 6G2.5mm² | 14.2 | 138 | 356 | |
| 7G2.5mm² | 14.2 | 161 | 376 | |
| 8G2.5mm² | 15.3 | 184 | 389 | |
| 10G2.5mm² | 17.7 | 230 | 491 | |
| 12G2.5mm² | 18.2 | 276 | 562 | |
| 19G2.5mm² | 21.2 | 438 | 827 | |
| 25G2.5mm² | 25.1 | 576 | 1094 | |
| 30G2.5mm² | 26.5 | 691 | 1278 | |
| 37G2.5mm² | 29.4 | 852 | 1591 | |
| 2X4.0mm² | 12.1 | 74 | 208 | |
| 3G4.0mm² | 12.8 | 111 | 265 | |
| 4G4.0mm² | 13.9 | 148 | 327 | |
| 5G4.0mm² | 15.1 | 184 | 392 | |
| 2X6.0mm² | 13.8 | 110 | 276 | |
| 3G6.0mm² | 14.6 | 165 | 357 | |
| 4G6.0mm² | 15.9 | 220 | 446 | |
| 5G6.0mm² | 17.3 | 274 | 538 | |
| 2X10mm² | 15.8 | 184 | 389 | |
| 3G10mm² | 16.8 | 275 | 514 | |
| 4G10mm² | 18.3 | 367 | 650 | |
| 5G10mm² | 20.0 | 459 | 791 | |
| 2X16mm² | 18.1 | 293 | 548 | |
| 3G16mm² | 19.3 | 440 | 738 | |
| 4G16mm² | 21.5 | 587 | 962 | |
| 5G16mm² | 23.6 | 733 | 1175 | |
| 2X25mm² | 22.1 | 459 | 828 | |
| 3G25mm² | 23.6 | 688 | 1123 | |
| 4G25mm² | 25.9 | 918 | 1439 | |
| 5G25mm² | 29.3 | 1147 | 1820 | |
| 2X35mm² | 25.3 | 642 | 1112 | |
| 3G35mm² | 27.0 | 963 | 1517 | |
| 4G35mm² | 30.0 | 1283 | 1976 | |
| 5G35mm² | 33.4 | 1604 | 2456 | |
| 2X50mm² | 29.4 | 916 | 1534 | |
| 3G50mm² | 31.3 | 1374 | 2104 | |
| 4G50mm² | 34.8 | 1832 | 2742 | |
| 5G50mm² | 38.7 | 2290 | 3406 | |
| 2X70mm² | 33.9 | 1283 | 2084 | |
| 3G70mm² | 36.1 | 1925 | 2872 | |
| 4G70mm² | 40.2 | 2567 | 3746 | |
| 5G70mm² | 44.7 | 3208 | 4652 | |
| 2X95mm² | 38.3 | 1741 | 2737 | |
| 3G95mm² | 40.9 | 2612 | 3790 | |
| 4G95mm² | 45.4 | 3483 | 4947 | |
| 5G95mm² | 50.5 | 4354 | 6144 | |
| 2X120mm² | 42.5 | 2200 | 3411 | |
| 3G120mm² | 45.8 | 3299 | 4778 | |
| 4G120mm² | 50.4 | 4399 | 6181 | |
| 5G120mm² | 56.9 | 5499 | 7784 | |
| 2X150mm² | 47.0 | 2749 | 4195 | |
| 3G150mm² | 50.3 | 4123 | 5847 | |
| 4G150mm² | 57.1 | 5497 | 7806 | |
| 5G150mm² | 63.3 | 6871 | 9679 | |
| 2X185mm² | 52.8 | 3387 | 5246 | |
| 3G185mm² | 56.9 | 5080 | 7344 | |
| 4G185mm² | 63.1 | 6774 | 9569 | |
| 5G185mm² | 70.0 | 8467 | 11868 | |
| 2X240mm² | 59.0 | 4389 | 6658 | |
| 3G240mm² | 63.1 | 6583 | 9284 | |
| 4G240mm² | 70.4 | 8778 | 12188 | |
| 5G240mm² | 78.3 | 10972 | 15159 |
