应用范围：
| 物料编号 | 芯数 x 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 2X4.0mm² | 12.0 | 75.4 | 206 | |
| 3G4.0mm² | 12.7 | 113.1 | 267 | |
| 4G4.0mm² | 14.1 | 150.8 | 343 | |
| 5G4.0mm² | 15.6 | 188.5 | 439 | |
| 2X6.0mm² | 13.8 | 113.1 | 283 | |
| 3G6.0mm² | 14.6 | 169.7 | 369 | |
| 4G6.0mm² | 16.0 | 226.3 | 465 | |
| 5G6.0mm² | 17.6 | 282.8 | 597 | |
| 2X10mm² | 17.0 | 188.5 | 434 | |
| 3G10mm² | 18.0 | 282.8 | 574 | |
| 4G10mm² | 20.4 | 377.1 | 763 | |
| 5G10mm² | 22.7 | 471.4 | 990 | |
| 2X16mm² | 20.2 | 302.0 | 641 | |
| 3G16mm² | 21.4 | 453.0 | 854 | |
| 4G16mm² | 24.0 | 604.0 | 1117 | |
| 5G16mm² | 26.6 | 755.0 | 1444 | |
| 2X25mm² | 25.0 | 472.2 | 984 | |
| 3G25mm² | 26.5 | 708.3 | 1317 | |
| 4G25mm² | 30.0 | 944.4 | 1749 | |
| 5G25mm² | 33.6 | 1180.5 | 2289 | |
| 2X35mm² | 28.0 | 660.7 | 1286 | |
| 3G35mm² | 30.1 | 991.1 | 1767 | |
| 4G35mm² | 33.9 | 1321.5 | 2334 | |
| 5G35mm² | 37.5 | 1651.9 | 2996 |
