| 物料编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 2PX0.14mm² | 6.1 | 14.7 | 51 | |
| 3PX0.14mm² | 6.5 | 18.4 | 59 | |
| 4PX0.14mm² | 7.2 | 22.3 | 73 | |
| 5PX0.14mm² | 7.7 | 28.9 | 85 | |
| 6PX0.14mm² | 8.2 | 33.3 | 95 | |
| 7PX0.14mm² | 8.8 | 37.6 | 105 | |
| 8PX0.14mm² | 9.6 | 42.3 | 122 | |
| 10PX0.14mm² | 10.3 | 49.6 | 140 | |
| 12PX0.14mm² | 10.7 | 55.9 | 160 | |
| 14PX0.14mm² | 11.2 | 62.8 | 174 | |
| 15PX0.14mm² | 11.9 | 67.1 | 191 | |
| 16PX0.14mm² | 11.9 | 69.8 | 197 | |
| 18PX0.14mm² | 12.5 | 76.9 | 214 | |
| 20PX0.14mm² | 13.2 | 84.0 | 239 | |
| 25PX0.14mm² | 14.5 | 101.5 | 279 | |
| 2PX0.25mm² | 6.8 | 20.6 | 62 | |
| 3PX0.25mm² | 7.4 | 26.6 | 78 | |
| 4PX0.25mm² | 8.0 | 35.6 | 96 | |
| 5PX0.25mm² | 8.6 | 42.3 | 108 | |
| 6PX0.25mm² | 9.2 | 49.1 | 122 | |
| 7PX0.25mm² | 10.1 | 55.9 | 142 | |
| 8PX0.25mm² | 11.0 | 63.1 | 164 | |
| 10PX0.25mm² | 12.0 | 75.1 | 196 | |
| 12PX0.25mm² | 12.3 | 85.8 | 218 | |
| 14PX0.25mm² | 13.1 | 97.3 | 245 | |
| 15PX0.25mm² | 13.7 | 103.9 | 261 | |
| 16PX0.25mm² | 13.7 | 108.8 | 269 | |
| 18PX0.25mm² | 14.3 | 120.5 | 294 | |
| 20PX0.25mm² | 15.0 | 132.3 | 320 | |
| 25PX0.25mm² | 16.7 | 161.1 | 386 | |
| 2PX0.34mm² | 7.1 | 24.9 | 69 | |
| 3PX0.34mm² | 7.8 | 35.4 | 91 | |
| 4PX0.34mm² | 8.4 | 43.8 | 109 | |
| 5PX0.34mm² | 9.0 | 52.4 | 124 | |
| 6PX0.34mm² | 9.9 | 61.2 | 145 | |
| 7PX0.34mm² | 10.8 | 69.9 | 168 | |
| 8PX0.34mm² | 11.6 | 78.9 | 188 | |
| 10PX0.34mm² | 12.6 | 94.6 | 225 | |
| 12PX0.34mm² | 13.0 | 109.0 | 252 | |
| 14PX0.34mm² | 13.6 | 124.1 | 277 | |
| 15PX0.34mm² | 14.5 | 132.6 | 302 | |
| 16PX0.34mm² | 14.5 | 139.3 | 313 | |
| 18PX0.34mm² | 15.4 | 154.7 | 351 | |
| 20PX0.34mm² | 16.1 | 170.0 | 382 | |
| 25PX0.34mm² | 18.1 | 208.1 | 471 | |
| 2PX0.5mm² | 8.1 | 37.4 | 97 | |
| 3PX0.5mm² | 8.7 | 49.0 | 119 | |
| 4PX0.5mm² | 9.7 | 61.1 | 151 | |
| 5PX0.5mm² | 10.7 | 73.4 | 178 | |
| 6PX0.5mm² | 11.6 | 85.8 | 203 | |
| 7PX0.5mm² | 12.7 | 98.2 | 235 | |
| 8PX0.5mm² | 13.7 | 111.1 | 264 | |
| 10PX0.5mm² | 15.0 | 133.8 | 318 | |
| 12PX0.5mm² | 15.6 | 154.6 | 367 | |
| 14PX0.5mm² | 16.4 | 176.5 | 404 | |
| 15PX0.5mm² | 17.5 | 188.8 | 440 | |
| 16PX0.5mm² | 17.5 | 198.6 | 457 | |
| 18PX0.5mm² | 18.6 | 220.8 | 512 | |
| 20PX0.5mm² | 19.5 | 259.1 | 576 | |
| 25PX0.5mm² | 21.9 | 316.2 | 707 |
