应用范围：
| 物料编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 2X0.14mm² | 4.5 | 2.7 | 25 | |
| 3X0.14mm² | 4.7 | 4.0 | 28 | |
| 4X0.14mm² | 5.0 | 5.3 | 32 | |
| 5X0.14mm² | 5.3 | 6.6 | 36 | |
| 6X0.14mm² | 5.6 | 8.0 | 41 | |
| 7X0.14mm² | 5.9 | 9.3 | 45 | |
| 8X0.14mm² | 6.3 | 10.6 | 51 | |
| 10X0.14mm² | 7.0 | 13.3 | 61 | |
| 12X0.14mm² | 8.4 | 15.9 | 74 | |
| 14X0.14mm² | 8.7 | 18.6 | 81 | |
| 15X0.14mm² | 9.0 | 19.9 | 85 | |
| 16X0.14mm² | 9.0 | 21.3 | 87 | |
| 18X0.14mm² | 9.6 | 23.9 | 97 | |
| 20X0.14mm² | 9.7 | 26.6 | 102 | |
| 24X0.14mm² | 10.5 | 31.9 | 117 | |
| 25X0.14mm² | 10.6 | 33.2 | 119 | |
| 30X0.14mm² | 11.6 | 39.9 | 144 | |
| 36X0.14mm² | 13.0 | 47.8 | 173 | |
| 2X0.25mm² | 4.9 | 4.7 | 31 | |
| 3X0.25mm² | 5.1 | 7.1 | 35 | |
| 4X0.25mm² | 5.4 | 9.5 | 41 | |
| 5X0.25mm² | 5.8 | 11.9 | 47 | |
| 6X0.25mm² | 6.2 | 14.2 | 53 | |
| 7X0.25mm² | 6.6 | 16.6 | 60 | |
| 8X0.25mm² | 7.0 | 19.0 | 67 | |
| 10X0.25mm² | 8.2 | 23.7 | 89 | |
| 12X0.25mm² | 9.5 | 28.5 | 97 | |
| 14X0.25mm² | 9.8 | 33.2 | 107 | |
| 15X0.25mm² | 10.2 | 35.6 | 113 | |
| 16X0.25mm² | 10.2 | 38.0 | 116 | |
| 18X0.25mm² | 11.1 | 42.7 | 136 | |
| 20X0.25mm² | 11.2 | 47.5 | 144 | |
| 24X0.25mm² | 12.3 | 57.0 | 172 | |
| 25X0.25mm² | 12.5 | 59.3 | 175 | |
| 30X0.25mm² | 13.4 | 71.2 | 202 | |
| 36X0.25mm² | 14.8 | 85.4 | 236 | |
| 2X0.34mm² | 5.1 | 6.5 | 35 | |
| 3X0.34mm² | 5.3 | 9.7 | 40 | |
| 4X0.34mm² | 5.7 | 12.9 | 46 | |
| 5X0.34mm² | 6.1 | 16.1 | 54 | |
| 6X0.34mm² | 6.5 | 19.4 | 61 | |
| 7X0.34mm² | 6.9 | 22.6 | 69 | |
| 8X0.34mm² | 7.8 | 25.8 | 85 | |
| 10X0.34mm² | 8.7 | 32.3 | 103 | |
| 12X0.34mm² | 10.0 | 38.7 | 112 | |
| 14X0.34mm² | 10.3 | 45.2 | 124 | |
| 15X0.34mm² | 11.0 | 48.4 | 137 | |
| 16X0.34mm² | 11.0 | 51.6 | 141 | |
| 18X0.34mm² | 11.9 | 58.1 | 164 | |
| 20X0.34mm² | 12.1 | 64.5 | 173 | |
| 24X0.34mm² | 13.0 | 77.5 | 201 | |
| 25X0.34mm² | 13.2 | 80.7 | 205 | |
| 30X0.34mm² | 14.4 | 96.8 | 245 | |
| 36X0.34mm² | 15.9 | 116.2 | 286 |
