应用范围：
| 编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 2X4.0mm² | 13.0 | 103 | 223 |
| 2 | 3G4.0mm² | 13.5 | 142 | 290 |
| 3 | 4G4.0mm² | 14.7 | 183 | 361 |
| 4 | 5G4.0mm² | 16.3 | 224 | 440 |
| 5 | 2X6.0mm² | 14.4 | 144 | 293 |
| 6 | 3G6.0mm² | 15.3 | 202 | 385 |
| 7 | 4G6.0mm² | 16.9 | 261 | 489 |
| 8 | 5G6.0mm² | 18.7 | 320 | 599 |
| 9 | 2X10mm² | 16.6 | 224 | 413 |
| 10 | 3G10mm² | 17.8 | 319 | 559 |
| 11 | 4G10mm² | 19.7 | 432 | 731 |
| 12 | 5G10mm² | 22.0 | 531 | 903 |
| 13 | 2X16mm² | 19.3 | 357 | 604 |
| 14 | 3G16mm² | 20.6 | 508 | 812 |
| 15 | 4G16mm² | 23.0 | 663 | 1051 |
| 16 | 5G16mm² | 25.6 | 818 | 1298 |
| 17 | 2X25mm² | 23.7 | 536 | 906 |
| 18 | 3G25mm² | 25.3 | 772 | 1225 |
| 19 | 4G25mm² | 28.1 | 1011 | 1585 |
| 20 | 5G25mm² | 31.3 | 1252 | 1957 |
| 21 | 2X35mm² | 26.9 | 730 | 1191 |
| 22 | 3G35mm² | 28.7 | 1058 | 1624 |
| 23 | 4G35mm² | 31.9 | 1390 | 2105 |
| 24 | 5G35mm² | 35.8 | 1723 | 2629 |
| 25 | 2X50mm² | 31.8 | 1021 | 1658 |
| 26 | 3G50mm² | 33.9 | 1487 | 2270 |
| 27 | 4G50mm² | 38.0 | 1958 | 2973 |
| 28 | 5G50mm² | 42.1 | 2467 | 3703 |
| 29 | 2X70mm² | 35.9 | 1402 | 2186 |
| 30 | 3G70mm² | 38.6 | 2054 | 3050 |
| 31 | 4G70mm² | 43.2 | 2746 | 4027 |
| 32 | 5G70mm² | 47.9 | 3409 | 4964 |
| 33 | 2X95mm² | 41.5 | 1914 | 2953 |
| 34 | 3G95mm² | 44.6 | 2799 | 4116 |
| 35 | 4G95mm² | 49.4 | 3691 | 5334 |
| 36 | 5G95mm² | 54.8 | 4587 | 6582 |
| 37 | 2X120mm² | 45.3 | 2390 | 3602 |
| 38 | 3G120mm² | 48.8 | 3504 | 5040 |
| 39 | 4G120mm² | 54.0 | 4628 | 6541 |
| 40 | 5G120mm² | 59.8 | 5819 | 8140 |
| 41 | 2X150mm² | 50.2 | 2961 | 4427 |
| 42 | 3G150mm² | 54.0 | 4352 | 6212 |
| 43 | 4G150mm² | 59.8 | 5817 | 8137 |
| 44 | 5G150mm² | 66.5 | 7229 | 10073 |
| 45 | 2X185mm² | 55.2 | 3622 | 5373 |
| 46 | 3G185mm² | 59.4 | 5398 | 7624 |
| 47 | 4G185mm² | 66.0 | 7128 | 9935 |
| 48 | 5G185mm² | 73.3 | 8864 | 12298 |
| 49 | 2X240mm² | 62.4 | 4722 | 6941 |
| 50 | 3G240mm² | 66.7 | 6943 | 9702 |
| 51 | 4G240mm² | 74.0 | 9179 | 12654 |
| 52 | 5G240mm² | 82.0 | 11420 | 15637 |
