| 物料编号 | 规格 | 导体根数 | 导体直径mm | 绝缘厚度mm | 绝缘外径mm | 电缆重量kg/km |
| 1 | 14AWG | 7 | 0.62 | 0.76 | 3.4 | 29 |
| 2 | 12AWG | 7 | 0.77 | 0.76 | 3.8 | 42 |
| 3 | 10AWG | 7 | 0.98 | 0.76 | 4.5 | 63 |
| 4 | 8AWG | 7 | 1.23 | 1.14 | 6.0 | 104 |
| 5 | 6AWG | 7 | 1.55 | 1.52 | 7.7 | 168 |
| 6 | 4AWG | 7 | 1.96 | 1.52 | 8.9 | 252 |
| 7 | 2AWG | 7 | 2.47 | 1.52 | 10.5 | 380 |
| 8 | 1AWG | 19 | 1.68 | 2.03 | 12.5 | 487 |
| 9 | 1/0AWG | 19 | 1.84 | 2.03 | 13.3 | 571 |
| 10 | 2/0AWG | 19 | 2.12 | 2.03 | 14.7 | 736 |
| 11 | 3/0AWG | 19 | 2.39 | 2.03 | 16.0 | 914 |
| 12 | 4/0AWG | 37 | 1.91 | 2.03 | 17.4 | 1117 |
| 13 | 250Kcmil | 37 | 2.09 | 2.41 | 19.5 | 1356 |
| 14 | 300Kcmil | 37 | 2.28 | 2.41 | 20.8 | 1590 |
| 15 | 350Kcmil | 37 | 2.47 | 2.41 | 22.1 | 1844 |
