应用范围：
| 编号 | 规格 | 导体结构 | 绝缘厚度mm | 绝缘外径mm | 电缆重量kg/km | |
| 1 | 22AWG | 17 | 0.16 | 0.76 | 2.35 | 9 |
| 2 | 20AWG | 26 | 0.16 | 0.76 | 2.55 | 12 |
| 3 | 18AWG | 41 | 0.16 | 0.76 | 2.80 | 16 |
| 4 | 16AWG | 26 | 0.25 | 0.76 | 3.05 | 21 |
| 5 | 14AWG | 41 | 0.25 | 0.76 | 3.45 | 29 |
| 6 | 12AWG | 65 | 0.25 | 0.76 | 3.95 | 42 |
| 7 | 10AWG | 105 | 0.25 | 0.76 | 5.0 | 66 |
| 8 | 8AWG | 168 | 0.25 | 1.15 | 6.7 | 111 |
| 9 | 6AWG | 266 | 0.25 | 1.53 | 8.5 | 177 |
| 10 | 4AWG | 437 | 0.25 | 1.53 | 10.0 | 268 |
| 11 | 2AWG | 646 | 0.25 | 1.53 | 11.5 | 375 |
| 12 | 1AWG | 847 | 0.25 | 2.03 | 13.7 | 508 |
| 13 | 1/0AWG | 1050 | 0.25 | 2.03 | 15.0 | 622 |
| 14 | 2/0AWG | 1349 | 0.25 | 2.03 | 16.3 | 770 |
| 15 | 3/0AWG | 1702 | 0.25 | 2.03 | 18.0 | 957 |
| 16 | 4/0AWG | 2146 | 0.25 | 2.03 | 19.3 | 1162 |
| 17 | 250Kcmil | 2546 | 0.25 | 2.41 | 21.2 | 1390 |
| 18 | 300Kcmil | 3096 | 0.25 | 2.41 | 22.9 | 1680 |
| 19 | 350Kcmil | 1393 | 0.4 | 2.41 | 24.1 | 1911 |
| 20 | 400Kcmil | 1592 | 0.4 | 2.41 | 25.4 | 2160 |
| 21 | 450Kcmil | 1790 | 0.4 | 2.41 | 26.7 | 2410 |
| 22 | 500Kcmil | 1989 | 0.4 | 2.41 | 27.8 | 2623 |
