应用范围：
| 物料编号 | 规格 | 导体结构 | 绝缘厚度mm | 绝缘外径mm | 电缆重量约kg/km | |
| 1 | 26AWG | 7 | 0.16 | 0.76 | 2.05 | 6.1 |
| 2 | 24AWG | 11 | 0.16 | 0.76 | 2.20 | 7.2 |
| 3 | 22AWG | 17 | 0.16 | 0.76 | 2.35 | 9.2 |
| 4 | 20AWG | 26 | 0.16 | 0.76 | 2.55 | 11.7 |
| 5 | 18AWG | 41 | 0.16 | 0.76 | 2.80 | 15.5 |
| 6 | 16AWG | 26 | 0.25 | 0.76 | 3.10 | 20.5 |
| 7 | 14AWG | 41 | 0.25 | 0.76 | 3.45 | 28.9 |
| 8 | 12AWG | 65 | 0.25 | 0.76 | 3.95 | 41.8 |
| 9 | 10AWG | 105 | 0.25 | 0.76 | 5.00 | 65.6 |
| 10 | 8AWG | 168 | 0.25 | 1.15 | 6.60 | 111.0 |
| 11 | 6AWG | 266 | 0.25 | 1.53 | 8.50 | 177.2 |
| 12 | 4AWG | 437 | 0.25 | 1.53 | 10.00 | 268.0 |
| 13 | 2AWG | 646 | 0.25 | 1.53 | 12.00 | 375.2 |
| 14 | 1AWG | 847 | 0.25 | 2.03 | 13.70 | 508.1 |
| 15 | 1/0AWG | 1050 | 0.25 | 2.03 | 15.00 | 622.2 |
| 16 | 2/0AWG | 1349 | 0.25 | 2.03 | 17.00 | 770.5 |
| 17 | 3/0AWG | 1702 | 0.25 | 2.03 | 18.00 | 956.9 |
| 18 | 4/0AWG | 2146 | 0.25 | 2.03 | 20.00 | 1161.9 |
| 19 | 250Kcmil | 2546 | 0.25 | 2.42 | 22.00 | 1390.3 |
| 20 | 300Kcmil | 3096 | 0.25 | 2.42 | 23.50 | 1680.2 |
| 21 | 350Kcmil | 1393 | 0.4 | 2.42 | 24.00 | 1910.6 |
| 22 | 400Kcmil | 1592 | 0.4 | 2.42 | 28.50 | 2160.3 |
| 23 | 450Kcmil | 1790 | 0.4 | 2.42 | 26.50 | 2409.8 |
| 24 | 500Kcmil | 1989 | 0.4 | 2.42 | 29.00 | 2623.3 |
