应用范围：
| 物料编号 | 芯数 X 标称截面AWG | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1X2X28AWG | 3.9 | 6.4 | 17 | |
| 2X2X28AWG | 5.2 | 10.5 | 28 | |
| 3X2X28AWG | 5.7 | 12.8 | 35 | |
| 4X2X28AWG | 6.1 | 15.2 | 40 | |
| 5X2X28AWG | 6.5 | 17.7 | 46 | |
| 6X2X28AWG | 7.0 | 17.3 | 46 | |
| 7X2X28AWG | 7.0 | 18.8 | 49 | |
| 8X2X28AWG | 7.6 | 24.2 | 63 | |
| 10X2X28AWG | 8.8 | 32.9 | 82 | |
| 12X2X28AWG | 9.3 | 36.4 | 93 | |
| 16X2X28AWG | 10.3 | 44.7 | 115 | |
| 20X2X28AWG | 11.2 | 53.1 | 134 | |
| 25X2X28AWG | 12.4 | 63.5 | 162 | |
| 1X2X26AWG | 4.1 | 8.1 | 20 | |
| 2X2X26AWG | 5.5 | 13.6 | 33 | |
| 3X2X26AWG | 6.1 | 17.0 | 41 | |
| 4X2X26AWG | 6.5 | 20.7 | 48 | |
| 5X2X26AWG | 7.0 | 24.4 | 55 | |
| 6X2X26AWG | 7.5 | 25.7 | 57 | |
| 7X2X26AWG | 7.5 | 28.3 | 61 | |
| 8X2X26AWG | 8.2 | 37.5 | 79 | |
| 10X2X26AWG | 9.5 | 46.1 | 100 | |
| 12X2X26AWG | 10.0 | 52.0 | 114 | |
| 16X2X26AWG | 11.1 | 65.0 | 142 | |
| 20X2X26AWG | 12.1 | 78.3 | 166 | |
| 25X2X26AWG | 13.4 | 94.6 | 202 | |
| 1X2X24AWG | 4.3 | 10.0 | 22 | |
| 2X2X24AWG | 5.8 | 17.3 | 38 | |
| 3X2X24AWG | 6.4 | 22.3 | 48 | |
| 4X2X24AWG | 6.9 | 27.6 | 57 | |
| 5X2X24AWG | 7.6 | 32.9 | 69 | |
| 6X2X24AWG | 8.3 | 41.2 | 84 | |
| 7X2X24AWG | 8.3 | 45.3 | 90 | |
| 8X2X24AWG | 9.1 | 51.0 | 103 | |
| 10X2X24AWG | 10.4 | 62.8 | 124 | |
| 12X2X24AWG | 10.8 | 71.8 | 142 | |
| 16X2X24AWG | 9.8 | 90.9 | 129 | |
| 20X2X24AWG | 13.1 | 110.4 | 210 | |
| 25X2X24AWG | 14.6 | 134.4 | 255 | |
| 1X2X22AWG | 4.7 | 13.2 | 27 | |
| 2X2X22AWG | 6.7 | 23.3 | 49 | |
| 3X2X22AWG | 7.1 | 30.7 | 61 | |
| 4X2X22AWG | 7.9 | 41.2 | 78 | |
| 5X2X22AWG | 8.5 | 49.2 | 91 | |
| 6X2X22AWG | 9.3 | 57.4 | 108 | |
| 7X2X22AWG | 9.3 | 63.7 | 116 | |
| 8X2X22AWG | 10.2 | 71.9 | 133 | |
| 10X2X22AWG | 11.9 | 88.9 | 167 | |
| 12X2X22AWG | 12.2 | 102.4 | 186 | |
| 16X2X22AWG | 13.6 | 130.9 | 235 | |
| 1X2X20AWG | 5.3 | 18.0 | 35 | |
| 2X2X20AWG | 7.6 | 35.1 | 67 | |
| 3X2X20AWG | 8.2 | 46.4 | 83 | |
| 4X2X20AWG | 9.1 | 58.0 | 104 | |
| 5X2X20AWG | 10.0 | 69.8 | 126 | |
| 6X2X20AWG | 11.0 | 62.6 | 124 | |
| 7X2X20AWG | 11.0 | 72.1 | 137 | |
| 8X2X20AWG | 12.0 | 103.3 | 186 | |
| 10X2X20AWG | 14.1 | 127.9 | 232 | |
| 12X2X20AWG | 14.5 | 148.3 | 261 | |
| 16X2X20AWG | 16.1 | 190.9 | 331 | |
| 1X2X18AWG | 5.9 | 24.5 | 45 | |
| 2X2X18AWG | 8.3 | 48.0 | 82 | |
| 3X2X18AWG | 9.1 | 65.1 | 109 | |
| 4X2X18AWG | 10.1 | 82.5 | 136 | |
| 5X2X18AWG | 11.1 | 100.1 | 166 |
