应用范围：
| 编号 | 芯数 X 标称截面AWG | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 2X16AWG | 7.1 | 24 | 65 |
| 2 | 3G16AWG | 7.5 | 36 | 84 |
| 3 | 4G16AWG | 8.4 | 48 | 109 |
| 4 | 5G16AWG | 9.3 | 60 | 136 |
| 5 | 6G16AWG | 10.3 | 72 | 161 |
| 6 | 7G16AWG | 11.3 | 84 | 199 |
| 7 | 8G16AWG | 12.4 | 96 | 235 |
| 8 | 10G16AWG | 13.1 | 121 | 252 |
| 9 | 12G16AWG | 13.7 | 145 | 293 |
| 10 | 16G16AWG | 15.1 | 193 | 374 |
| 11 | 2X14AWG | 8.1 | 38 | 90 |
| 12 | 3G14AWG | 8.6 | 57 | 117 |
| 13 | 4G14AWG | 9.5 | 76 | 152 |
| 14 | 5G14AWG | 10.6 | 95 | 188 |
| 15 | 6G14AWG | 11.7 | 114 | 223 |
| 16 | 7G14AWG | 12.8 | 133 | 274 |
| 17 | 8G14AWG | 13.9 | 152 | 317 |
| 18 | 10G14AWG | 15.1 | 190 | 358 |
| 19 | 12G14AWG | 15.6 | 228 | 409 |
| 20 | 2X12AWG | 9.1 | 60 | 121 |
| 21 | 3G12AWG | 9.8 | 90 | 166 |
| 22 | 4G12AWG | 11.0 | 121 | 215 |
| 23 | 5G12AWG | 12.2 | 151 | 266 |
| 24 | 6G12AWG | 13.4 | 181 | 316 |
| 25 | 7G12AWG | 14.7 | 211 | 387 |
| 26 | 8G12AWG | 16.1 | 241 | 456 |
| 27 | 10G12AWG | 17.5 | 301 | 515 |
| 28 | 12G12AWG | 18.0 | 362 | 591 |
| 29 | 2X10AWG | 11.4 | 97 | 184 |
| 30 | 3G10AWG | 12.3 | 146 | 251 |
| 31 | 4G10AWG | 13.6 | 195 | 325 |
| 32 | 5G10AWG | 15.1 | 243 | 418 |
| 33 | 2X8AWG | 14.4 | 156 | 293 |
| 34 | 3G8AWG | 15.4 | 234 | 398 |
| 35 | 4G8AWG | 17.0 | 311 | 507 |
| 36 | 5G8AWG | 18.7 | 389 | 652 |
| 37 | 2X6AWG | 18.6 | 247 | 469 |
| 38 | 3G6AWG | 19.9 | 370 | 639 |
| 39 | 4G6AWG | 22.4 | 493 | 838 |
| 40 | 5G6AWG | 24.9 | 616 | 1091 |
| 41 | 2X4AWG | 22.0 | 405 | 704 |
| 42 | 3G4AWG | 23.7 | 608 | 976 |
| 43 | 4G4AWG | 26.1 | 810 | 1252 |
| 44 | 5G4AWG | 29.4 | 1013 | 1651 |
| 45 | 2X2AWG | 26.0 | 599 | 1012 |
| 46 | 3G2AWG | 27.6 | 898 | 1374 |
| 47 | 4G2AWG | 31.2 | 1198 | 1826 |
| 48 | 5G2AWG | 34.6 | 1497 | 2356 |
