应用范围：
| 物料编号 | 芯数 X 标称截面AWG | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 2X16AWG | 7.8 | 40 | 96 | |
| 3G16AWG | 8.2 | 53 | 117 | |
| 4G16AWG | 9.1 | 68 | 147 | |
| 5G16AWG | 10.0 | 82 | 179 | |
| 6G16AWG | 11.0 | 96 | 210 | |
| 7G16AWG | 12.0 | 111 | 254 | |
| 8G16AWG | 13.1 | 125 | 298 | |
| 10G16AWG | 13.8 | 152 | 318 | |
| 12G16AWG | 14.4 | 177 | 364 | |
| 2X14AWG | 8.8 | 57 | 125 | |
| 3G14AWG | 9.3 | 77 | 156 | |
| 4G14AWG | 10.2 | 98 | 197 | |
| 5G14AWG | 11.3 | 120 | 240 | |
| 6G14AWG | 12.4 | 141 | 282 | |
| 7G14AWG | 13.5 | 163 | 340 | |
| 8G14AWG | 14.6 | 185 | 391 | |
| 10G14AWG | 15.8 | 226 | 439 | |
| 12G14AWG | 16.3 | 266 | 495 | |
| 2X12AWG | 9.8 | 82 | 163 | |
| 3G12AWG | 10.5 | 113 | 213 | |
| 4G12AWG | 11.7 | 146 | 270 | |
| 5G12AWG | 12.9 | 179 | 329 | |
| 6G12AWG | 14.1 | 213 | 387 | |
| 7G12AWG | 15.4 | 246 | 468 | |
| 8G12AWG | 16.8 | 280 | 547 | |
| 10G12AWG | 18.2 | 344 | 617 | |
| 12G12AWG | 18.7 | 405 | 699 | |
| 2X10AWG | 12.0 | 124 | 236 | |
| 3G10AWG | 12.9 | 175 | 309 | |
| 4G10AWG | 14.2 | 227 | 394 | |
| 5G10AWG | 15.7 | 279 | 497 | |
| 2X8AWG | 15.0 | 190 | 363 | |
| 3G8AWG | 16.0 | 270 | 478 | |
| 4G8AWG | 17.6 | 352 | 599 | |
| 5G8AWG | 19.3 | 450 | 776 | |
| 2X6AWG | 19.2 | 307 | 582 | |
| 3G6AWG | 20.5 | 435 | 768 | |
| 4G6AWG | 23.0 | 566 | 991 | |
| 5G6AWG | 25.5 | 698 | 1272 | |
| 2X4AWG | 22.6 | 477 | 849 | |
| 3G4AWG | 24.3 | 685 | 1145 | |
| 4G4AWG | 26.7 | 897 | 1448 | |
| 5G4AWG | 30.0 | 1109 | 1889 | |
| 2X2AWG | 26.6 | 683 | 1196 | |
| 3G2AWG | 28.2 | 989 | 1586 | |
| 4G2AWG | 31.8 | 1299 | 2085 | |
| 5G2AWG | 35.2 | 1611 | 2664 |
