应用范围：
| 物料编号 | 规格 | 导体根数 | 导体直径mm | 绝缘厚度mm | 绝缘外径mm | 电缆重量kg/km |
| 1 | 14AWG | 7 | 0.62 | 1.52 | 5.0 | 46 |
| 2 | 12AWG | 7 | 0.78 | 1.52 | 5.5 | 62 |
| 3 | 10AWG | 7 | 0.98 | 1.52 | 6.1 | 85 |
| 4 | 8AWG | 7 | 1.23 | 1.78 | 7.5 | 127 |
| 5 | 6AWG | 7 | 1.56 | 1.78 | 8.4 | 182 |
| 6 | 4AWG | 7 | 1.96 | 1.78 | 9.8 | 267 |
| 7 | 2AWG | 7 | 2.47 | 1.78 | 11.3 | 401 |
| 8 | 1AWG | 19 | 1.69 | 2.29 | 13.3 | 537 |
| 9 | 1/0AWG | 19 | 1.89 | 2.29 | 14.3 | 636 |
| 10 | 2/0AWG | 19 | 2.13 | 2.29 | 15.5 | 777 |
| 11 | 3/0AWG | 19 | 2.39 | 2.29 | 16.8 | 987 |
| 12 | 4/0AWG | 19 | 2.68 | 2.29 | 18.3 | 1174 |
| 13 | 250Kcmil | 37 | 2.07 | 2.67 | 20.4 | 1399 |
| 14 | 300Kcmil | 37 | 2.27 | 2.67 | 21.7 | 1647 |
| 15 | 350Kcmil | 37 | 2.45 | 2.67 | 23.0 | 1893 |
| 16 | 400Kcmil | 37 | 2.62 | 1.65 | 22.2 | 2108 |
| 17 | 450Kcmil | 37 | 2.78 | 1.65 | 23.3 | 2358 |
| 18 | 500Kcmil | 37 | 2.93 | 2.67 | 26.4 | 2624 |
