| 物料编号 |
芯数 X 标称截面mm |
电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 2X24AWG | 3.5 | 3.7 | 17.8 |
| 2 | 3X24AWG | 3.6 | 5.5 | 20.6 |
| 3 | 4X24AWG | 3.8 | 7.4 | 23.8 |
| 4 | 5X24AWG | 4.1 | 9.2 | 27.8 |
| 5 | 2X22AWG | 3.8 | 5.8 | 21.2 |
| 6 | 3X22AWG | 4.0 | 8.7 | 26.0 |
| 7 | 4X22AWG | 4.2 | 11.6 | 30.3 |
| 8 | 5X22AWG | 4.5 | 14.5 | 35.2 |
| 9 | 2X20AWG | 4.2 | 9.3 | 27.3 |
| 10 | 3X20AWG | 4.4 | 14.0 | 34.1 |
| 11 | 4X20AWG | 4.6 | 18.6 | 39.9 |
| 12 | 5X20AWG | 5.0 | 23.3 | 47.6 |
| 13 | 2X18AWG | 4.6 | 14.8 | 34.4 |
| 14 | 3X18AWG | 4.8 | 22.1 | 43.9 |
| 15 | 4X18AWG | 5.1 | 29.5 | 53.2 |
| 16 | 5X18AWG | 5.6 | 36.9 | 64.7 |
| 17 | 2X16AWG | 5.1 | 23.6 | 46.3 |
| 18 | 3X16AWG | 5.4 | 35.4 | 61.4 |
| 19 | 4X16AWG | 5.7 | 47.2 | 74.7 |
| 20 | 5X16AWG | 6.2 | 59.0 | 90.2 |
| 21 | 2X14AWG | 5.8 | 37.7 | 63.6 |
| 22 | 3X14AWG | 6.1 | 56.6 | 85.6 |
| 23 | 4X14AWG | 6.6 | 75.4 | 108.1 |
| 24 | 5X14AWG | 7.2 | 94.3 | 131.5 |
| 25 | 2X12AWG | 6.8 | 59.6 | 92.4 |
| 26 | 3X12AWG | 7.2 | 89.4 | 127.0 |
| 27 | 4X12AWG | 7.8 | 119.3 | 161.4 |
| 28 | 5X12AWG | 8.5 | 149.1 | 196.5 |
| 29 | 2X10AWG | 7.8 | 94.5 | 131.5 |
| 30 | 3X10AWG | 8.3 | 141.7 | 184.7 |
| 31 | 4X10AWG | 9.0 | 188.9 | 236.7 |
| 32 | 5X10AWG | 10.0 | 236.1 | 293.7 |
