| 序号 | 芯数 X 标称截面AWG | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 2X20AWG | 6.5 | 20.5 | 61 |
| 2 | 3G20AWG | 6.8 | 26.2 | 72 |
| 3 | 4G20AWG | 7.6 | 32.5 | 90 |
| 4 | 5G20AWG | 8.1 | 41.8 | 108 |
| 5 | 6G20AWG | 9.0 | 48.6 | 127 |
| 6 | 7G20AWG | 9.6 | 55.3 | 144 |
| 7 | 8G20AWG | 10.5 | 62.4 | 176 |
| 8 | 10G20AWG | 11.4 | 74.4 | 195 |
| 9 | 12G20AWG | 11.7 | 85.2 | 216 |
| 10 | 16G20AWG | 13.0 | 108.3 | 273 |
| 11 | 18G20AWG | 13.9 | 120.0 | 307 |
| 12 | 20G20AWG | 14.5 | 131.7 | 334 |
| 13 | 24G20AWG | 16.1 | 155.7 | 410 |
| 14 | 30G20AWG | 17.2 | 187.9 | 468 |
| 15 | 36G20AWG | 18.6 | 221.0 | 551 |
| 16 | 40G20AWG | 20.0 | 260.4 | 643 |
| 17 | 2X18AWG | 7.0 | 27.4 | 73 |
| 18 | 3G18AWG | 7.5 | 36.1 | 92 |
| 19 | 4G18AWG | 8.4 | 48.3 | 118 |
| 20 | 5G18AWG | 9.0 | 58.1 | 138 |
| 21 | 6G18AWG | 9.9 | 67.9 | 162 |
| 22 | 7G18AWG | 10.6 | 77.7 | 191 |
| 23 | 8G18AWG | 11.6 | 87.9 | 225 |
| 24 | 10G18AWG | 12.6 | 105.9 | 250 |
| 25 | 12G18AWG | 12.9 | 122.5 | 278 |
| 26 | 16G18AWG | 14.4 | 157.3 | 353 |
| 27 | 18G18AWG | 15.1 | 175.0 | 388 |
| 28 | 20G18AWG | 16.0 | 192.6 | 440 |
| 29 | 24G18AWG | 17.8 | 228.5 | 532 |
| 30 | 30G18AWG | 19.0 | 278.1 | 610 |
| 31 | 36G18AWG | 20.5 | 345.2 | 736 |
| 32 | 40G18AWG | 22.1 | 381.8 | 835 |
| 33 | 2X16AWG | 7.8 | 40.3 | 96 |
| 34 | 3G16AWG | 8.2 | 53.5 | 117 |
| 35 | 4G16AWG | 9.1 | 67.6 | 147 |
| 36 | 5G16AWG | 10.0 | 81.8 | 179 |
| 37 | 6G16AWG | 11.0 | 96.2 | 210 |
| 38 | 7G16AWG | 12.0 | 110.5 | 254 |
| 39 | 8G16AWG | 13.1 | 125.3 | 298 |
| 40 | 10G16AWG | 13.8 | 152.1 | 318 |
| 41 | 12G16AWG | 14.4 | 177.4 | 364 |
| 42 | 16G16AWG | 15.8 | 229.8 | 456 |
| 43 | 18G16AWG | 16.8 | 256.2 | 512 |
| 44 | 20G16AWG | 17.8 | 282.6 | 579 |
| 45 | 25G16AWG | 19.8 | 348.3 | 693 |
| 46 | 36G16AWG | 23.0 | 507.1 | 986 |
| 47 | 2X14AWG | 8.8 | 56.5 | 125 |
| 48 | 3G14AWG | 9.3 | 76.9 | 156 |
| 49 | 4G14AWG | 10.2 | 98.2 | 197 |
| 50 | 5G14AWG | 11.3 | 119.8 | 240 |
| 51 | 6G14AWG | 12.4 | 141.4 | 282 |
| 52 | 7G14AWG | 13.5 | 163.1 | 340 |
| 53 | 8G14AWG | 14.6 | 185.2 | 391 |
| 54 | 10G14AWG | 15.8 | 226.4 | 439 |
| 55 | 12G14AWG | 16.3 | 265.7 | 495 |
| 56 | 16G14AWG | 18.1 | 346.6 | 634 |
| 57 | 18G14AWG | 19.2 | 387.3 | 712 |
| 58 | 20G14AWG | 20.3 | 444.3 | 820 |
| 59 | 24G14AWG | 22.8 | 528.6 | 1002 |
| 60 | 2X12AWG | 9.8 | 81.7 | 163 |
| 61 | 3G12AWG | 10.5 | 113.4 | 213 |
| 62 | 4G12AWG | 11.7 | 146.3 | 270 |
| 63 | 5G12AWG | 12.9 | 179.4 | 329 |
| 64 | 6G12AWG | 14.1 | 212.6 | 387 |
| 65 | 7G12AWG | 15.4 | 245.9 | 468 |
| 66 | 8G12AWG | 16.8 | 279.6 | 547 |
| 67 | 10G12AWG | 18.2 | 343.5 | 617 |
| 68 | 12G12AWG | 18.7 | 405.4 | 699 |
| 69 | 16G12AWG | 20.9 | 548.4 | 917 |
| 70 | 2X10AWG | 12.0 | 124.2 | 236 |
| 71 | 3G10AWG | 12.9 | 174.8 | 309 |
| 72 | 4G10AWG | 14.2 | 227.0 | 394 |
| 73 | 5G10AWG | 15.7 | 279.3 | 497 |
| 74 | 2X8AWG | 15.0 | 189.7 | 363 |
| 75 | 3G8AWG | 16.0 | 270.1 | 478 |
| 76 | 4G8AWG | 17.6 | 352.4 | 599 |
| 77 | 5G8AWG | 19.3 | 450.4 | 776 |
| 78 | 2X6AWG | 19.2 | 307.2 | 582 |
| 79 | 3G6AWG | 20.5 | 435.0 | 768 |
| 80 | 4G6AWG | 23.0 | 566.3 | 991 |
| 81 | 5G6AWG | 25.5 | 697.9 | 1272 |
| 82 | 2X4AWG | 22.6 | 476.8 | 849 |
| 83 | 3G4AWG | 24.3 | 684.6 | 1145 |
| 84 | 4G4AWG | 26.7 | 896.7 | 1448 |
| 85 | 5G4AWG | 30.0 | 1109.1 | 1889 |
| 86 | 2X2AWG | 26.6 | 683.2 | 1196 |
| 87 | 3G2AWG | 28.2 | 988.9 | 1586 |
| 88 | 4G2AWG | 31.8 | 1299.5 | 2085 |
| 89 | 5G2AWG | 35.2 | 1610.5 | 2664 |
