应用范围:
编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
1 | 2X0.5mm² | 6.2 | 21.5 | 56 |
2 | 3G0.5mm² | 6.4 | 26.9 | 64 |
3 | 4G0.5mm² | 6.9 | 32.9 | 74 |
4 | 5G0.5mm² | 7.7 | 39.6 | 92 |
5 | 6G0.5mm² | 8.2 | 45.8 | 105 |
6 | 7G0.5mm² | 8.7 | 52.0 | 117 |
7 | 8G0.5mm² | 9.2 | 58.3 | 131 |
8 | 10G0.5mm² | 10.7 | 72.3 | 155 |
9 | 12G0.5mm² | 11.9 | 85.3 | 181 |
10 | 14G0.5mm² | 12.3 | 96.0 | 198 |
11 | 15G0.5mm² | 13.2 | 102.8 | 223 |
12 | 16G0.5mm² | 13.2 | 107.5 | 228 |
13 | 18G0.5mm² | 14.0 | 119.5 | 254 |
14 | 20G0.5mm² | 14.2 | 129.6 | 269 |
15 | 24G0.5mm² | 15.4 | 151.9 | 321 |
16 | 25G0.5mm² | 15.7 | 157.1 | 330 |
17 | 30G0.5mm² | 17.2 | 184.8 | 403 |
18 | 36G0.5mm² | 19.0 | 218.5 | 470 |
19 | 2X0.75mm² | 6.6 | 27.3 | 66 |
20 | 3G0.75mm² | 6.9 | 35.1 | 76 |
21 | 4G0.75mm² | 7.7 | 44.1 | 97 |
22 | 5G0.75mm² | 8.3 | 52.7 | 112 |
23 | 6G0.75mm² | 8.8 | 61.4 | 128 |
24 | 7G0.75mm² | 9.3 | 70.0 | 144 |
25 | 8G0.75mm² | 9.9 | 78.8 | 168 |
26 | 10G0.75mm² | 11.6 | 97.9 | 191 |
27 | 12G0.75mm² | 13.4 | 116.6 | 236 |
28 | 14G0.75mm² | 13.8 | 132.0 | 260 |
29 | 15G0.75mm² | 14.4 | 140.7 | 276 |
30 | 16G0.75mm² | 14.4 | 147.7 | 284 |
31 | 18G0.75mm² | 15.3 | 164.6 | 318 |
32 | 20G0.75mm² | 15.5 | 179.4 | 337 |
33 | 24G0.75mm² | 17.2 | 226.5 | 436 |
34 | 25G0.75mm² | 17.4 | 234.2 | 439 |
35 | 30G0.75mm² | 18.8 | 274.4 | 524 |
36 | 36G0.75mm² | 21.4 | 325.3 | 641 |
37 | 2X1.0mm² | 7.6 | 34.4 | 87 |
38 | 3G1.0mm² | 7.9 | 44.7 | 100 |
39 | 4G1.0mm² | 8.5 | 55.8 | 118 |
40 | 5G1.0mm² | 9.1 | 67.0 | 138 |
41 | 6G1.0mm² | 9.7 | 78.3 | 159 |
42 | 7G1.0mm² | 10.3 | 97.8 | 188 |
43 | 8G1.0mm² | 11.4 | 110.7 | 229 |
44 | 10G1.0mm² | 13.1 | 125.6 | 243 |
45 | 12G1.0mm² | 14.7 | 149.1 | 285 |
46 | 14G1.0mm² | 15.6 | 170.1 | 330 |
47 | 15G1.0mm² | 16.5 | 182.0 | 360 |
48 | 16G1.0mm² | 16.5 | 191.4 | 371 |
49 | 18G1.0mm² | 17.8 | 228.5 | 437 |
50 | 20G1.0mm² | 18.4 | 248.4 | 479 |
51 | 24G1.0mm² | 19.9 | 291.9 | 573 |
52 | 25G1.0mm² | 20.1 | 302.1 | 578 |
53 | 30G1.0mm² | 22.0 | 355.8 | 701 |
54 | 36G1.0mm² | 24.3 | 421.5 | 820 |
55 | 2X1.5mm² | 8.8 | 46.9 | 117 |
56 | 3G1.5mm² | 9.2 | 69.1 | 144 |
57 | 4G1.5mm² | 9.9 | 85.9 | 171 |
58 | 5G1.5mm² | 10.8 | 103.0 | 205 |
59 | 6G1.5mm² | 12.0 | 121.1 | 246 |
60 | 7G1.5mm² | 12.8 | 138.3 | 287 |
61 | 8G1.5mm² | 14.0 | 155.9 | 338 |
62 | 10G1.5mm² | 15.8 | 180.3 | 347 |
63 | 12G1.5mm² | 18.1 | 230.3 | 440 |
64 | 14G1.5mm² | 19.2 | 261.2 | 503 |
65 | 15G1.5mm² | 20.0 | 278.4 | 535 |
66 | 16G1.5mm² | 20.0 | 292.6 | 552 |
67 | 18G1.5mm² | 21.3 | 326.3 | 618 |
68 | 20G1.5mm² | 21.8 | 356.7 | 669 |
69 | 24G1.5mm² | 23.9 | 420.6 | 817 |
70 | 25G1.5mm² | 24.7 | 436.6 | 856 |
71 | 30G1.5mm² | 26.5 | 514.6 | 1011 |
72 | 36G1.5mm² | 30.0 | 611.7 | 1226 |
73 | 2X2.5mm² | 10.2 | 77.7 | 171 |
74 | 3G2.5mm² | 10.7 | 103.3 | 204 |
75 | 4G2.5mm² | 11.8 | 131.0 | 250 |
76 | 5G2.5mm² | 12.7 | 158.4 | 297 |
77 | 6G2.5mm² | 13.7 | 185.9 | 344 |
78 | 7G2.5mm² | 14.7 | 213.4 | 406 |
79 | 8G2.5mm² | 16.2 | 242.1 | 480 |
80 | 10G2.5mm² | 19.3 | 300.8 | 543 |
81 | 12G2.5mm² | 22.2 | 357.7 | 658 |
82 | 14G2.5mm² | 23.4 | 408.9 | 754 |
83 | 15G2.5mm² | 24.4 | 436.4 | 804 |
84 | 16G2.5mm² | 24.4 | 460.0 | 831 |
85 | 18G2.5mm² | 26.7 | 514.8 | 970 |
86 | 20G2.5mm² | 27.1 | 563.6 | 1060 |
87 | 24G2.5mm² | 30.0 | 667.9 | 1296 |
88 | 25G2.5mm² | 30.4 | 692.8 | 1305 |
