编号 | 型号规格 | 导体材质 | 导体结构 | 绝缘材质 | 绝缘平均厚度 | 绝缘最薄厚度 | 绝缘外径约 | 护套材质 | 护套平均厚度 | 护套最薄厚度 | 护套外径约 | 导体电阻at20℃(Ω/km) |
1 | 1672 28AWG | 镀锡铜丝 | 7/0.12mm | PVC | 0.38mm | 0.33mm | 1.20mm | PVC | 0.38mm | 0.33mm | 2.0mm | 239 |
2 | 1672 26AWG | 镀锡铜丝 | 7/0.16mm | PVC | 0.38mm | 0.33mm | 1.30mm | PVC | 0.38mm | 0.33mm | 2.10mm | 150 |
3 | 1672 24AWG | 镀锡铜丝 | 11/0.16mm | PVC | 0.38mm | 0.33mm | 1.45mm | PVC | 0.38mm | 0.33mm | 2.25mm | 94.2 |
4 | 1672 22AWG | 镀锡铜丝 | 17/0.16mm | PVC | 0.38mm | 0.33mm | 1.60mm | PVC | 0.38mm | 0.33mm | 2.40mm | 59.4 |
5 | 1672 20AWG | 镀锡铜丝 | 26/0.16mm | PVC | 0.38mm | 0.33mm | 1.75mm | PVC | 0.38mm | 0.33mm | 2.55mm | 37.4 |
6 | 1672 18AWG | 镀锡铜丝 | 41/0.16mm | PVC | 0.38mm | 0.33mm | 2.05mm | PVC | 0.38mm | 0.33mm | 2.85mm | 23.5 |
7 | 1672 16AWG | 镀锡铜丝 | 26/0.25mm | PVC | 0.38mm | 0.33mm | 2.40mm | PVC | 0.38mm | 0.33mm | 3.20mm | 14.7 |
8 | 1672 14AWG | 镀锡铜丝 | 41/0.25mm | PVC | 0.38mm | 0.33mm | 2.80mm | PVC | 0.38mm | 0.33mm | 3.60mm | 9.25 |
9 | 1672 12AWG | 镀锡铜丝 | 65/0.25mm | PVC | 0.38mm | 0.33mm | 3.30mm | PVC | 0.38mm | 0.33mm | 4.10mm | 5.82 |
10 | 1672 10AWG | 镀锡铜丝 | 105/0.25mm | PVC | 0.38mm | 0.33mm | 4.30mm | PVC | 0.38mm | 0.33mm | 5.10mm | 3.66 |
