应用范围：
| 物料编号 | 芯数 X 标称截面AWG | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1X2X28AWG | 4.5 | 7.9 | 25 | |
| 2X2X28AWG | 6.3 | 12.9 | 44 | |
| 3X2X28AWG | 6.8 | 15.4 | 51 | |
| 4X2X28AWG | 7.3 | 18.1 | 59 | |
| 5X2X28AWG | 7.8 | 23.8 | 71 | |
| 6X2X28AWG | 8.6 | 24.2 | 75 | |
| 7X2X28AWG | 8.6 | 25.6 | 79 | |
| 8X2X28AWG | 9.2 | 31.8 | 98 | |
| 10X2X28AWG | 10.8 | 38.7 | 123 | |
| 12X2X28AWG | 11.3 | 42.6 | 140 | |
| 16X2X28AWG | 12.6 | 51.6 | 173 | |
| 20X2X28AWG | 13.8 | 60.9 | 203 | |
| 25X2X28AWG | 15.4 | 72.3 | 246 | |
| 1X2X26AWG | 4.7 | 9.6 | 27 | |
| 2X2X26AWG | 6.7 | 15.9 | 49 | |
| 3X2X26AWG | 7.1 | 19.7 | 58 | |
| 4X2X26AWG | 7.7 | 26.4 | 71 | |
| 5X2X26AWG | 8.3 | 30.8 | 82 | |
| 6X2X26AWG | 9.1 | 30.1 | 85 | |
| 7X2X26AWG | 9.1 | 32.7 | 91 | |
| 8X2X26AWG | 10.0 | 42.4 | 119 | |
| 10X2X26AWG | 11.7 | 52.0 | 149 | |
| 12X2X26AWG | 12.2 | 58.1 | 170 | |
| 16X2X26AWG | 13.4 | 71.9 | 205 | |
| 20X2X26AWG | 14.9 | 86.1 | 248 | |
| 25X2X26AWG | 16.6 | 103.4 | 301 | |
| 1X2X24AWG | 5.0 | 11.7 | 31 | |
| 2X2X24AWG | 6.9 | 20.1 | 53 | |
| 3X2X24AWG | 7.7 | 28.2 | 71 | |
| 4X2X24AWG | 8.5 | 34.1 | 88 | |
| 5X2X24AWG | 9.4 | 40.2 | 106 | |
| 6X2X24AWG | 10.1 | 46.3 | 121 | |
| 7X2X24AWG | 10.1 | 50.4 | 129 | |
| 8X2X24AWG | 11.0 | 56.6 | 148 | |
| 10X2X24AWG | 12.9 | 69.7 | 186 | |
| 12X2X24AWG | 13.2 | 78.9 | 206 | |
| 16X2X24AWG | 14.7 | 99.0 | 258 | |
| 20X2X24AWG | 16.4 | 119.5 | 313 | |
| 25X2X24AWG | 18.1 | 144.7 | 371 | |
| 1X2X22AWG | 5.3 | 14.7 | 36 | |
| 2X2X22AWG | 7.6 | 28.4 | 69 | |
| 3X2X22AWG | 8.2 | 36.4 | 84 | |
| 4X2X22AWG | 9.1 | 44.7 | 105 | |
| 5X2X22AWG | 9.8 | 53.2 | 122 | |
| 6X2X22AWG | 10.8 | 61.8 | 144 | |
| 7X2X22AWG | 10.8 | 68.1 | 156 | |
| 8X2X22AWG | 12.0 | 76.7 | 184 | |
| 10X2X22AWG | 13.9 | 94.7 | 224 | |
| 12X2X22AWG | 14.5 | 108.5 | 257 | |
| 16X2X22AWG | 15.9 | 137.8 | 316 | |
| 1X2X20AWG | 5.6 | 18.7 | 42 | |
| 2X2X20AWG | 8.1 | 36.5 | 80 | |
| 3X2X20AWG | 8.9 | 47.9 | 104 | |
| 4X2X20AWG | 9.7 | 59.8 | 125 | |
| 5X2X20AWG | 10.9 | 71.8 | 157 | |
| 6X2X20AWG | 12.0 | 64.8 | 155 | |
| 7X2X20AWG | 12.0 | 74.4 | 170 | |
| 8X2X20AWG | 12.8 | 105.7 | 224 | |
| 10X2X20AWG | 15.1 | 130.8 | 280 | |
| 12X2X20AWG | 15.7 | 151.3 | 322 | |
| 16X2X20AWG | 17.5 | 194.4 | 406 | |
| 1X2X18AWG | 6.4 | 25.8 | 56 | |
| 2X2X18AWG | 9.3 | 50.4 | 106 | |
| 3X2X18AWG | 10.2 | 67.7 | 139 | |
| 4X2X18AWG | 11.3 | 85.4 | 174 | |
| 5X2X18AWG | 12.4 | 103.4 | 211 |
