应用范围：
| 物料编号 | 芯数 X 标称截面AWG | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 2X16AWG | 7.1 | 24 | 69 | |
| 3G16AWG | 7.5 | 36 | 89 | |
| 4G16AWG | 8.4 | 48 | 115 | |
| 5G16AWG | 9.3 | 60 | 143 | |
| 6G16AWG | 10.3 | 72 | 170 | |
| 7G16AWG | 11.3 | 84 | 209 | |
| 8G16AWG | 12.4 | 96 | 248 | |
| 10G16AWG | 13.1 | 121 | 265 | |
| 12G16AWG | 13.7 | 145 | 308 | |
| 16G16AWG | 15.1 | 193 | 393 | |
| 2X14AWG | 8.1 | 38 | 95 | |
| 3G14AWG | 8.6 | 57 | 123 | |
| 4G14AWG | 9.5 | 76 | 160 | |
| 5G14AWG | 10.6 | 95 | 198 | |
| 6G14AWG | 11.7 | 114 | 235 | |
| 7G14AWG | 12.8 | 133 | 289 | |
| 8G14AWG | 13.9 | 152 | 334 | |
| 10G14AWG | 15.1 | 190 | 376 | |
| 12G14AWG | 15.6 | 228 | 430 | |
| 2X12AWG | 9.1 | 60 | 128 | |
| 3G12AWG | 9.8 | 90 | 174 | |
| 4G12AWG | 11.0 | 121 | 226 | |
| 5G12AWG | 12.2 | 151 | 280 | |
| 6G12AWG | 13.4 | 181 | 333 | |
| 7G12AWG | 14.7 | 211 | 407 | |
| 8G12AWG | 16.1 | 241 | 479 | |
| 10G12AWG | 17.5 | 301 | 542 | |
| 12G12AWG | 18.0 | 362 | 622 | |
| 2X10AWG | 11.4 | 97 | 194 | |
| 3G10AWG | 12.3 | 146 | 264 | |
| 4G10AWG | 13.6 | 195 | 342 | |
| 5G10AWG | 15.1 | 243 | 440 | |
| 2X8AWG | 14.4 | 156 | 308 | |
| 3G8AWG | 15.4 | 234 | 419 | |
| 4G8AWG | 17.0 | 311 | 534 | |
| 5G8AWG | 18.7 | 389 | 687 | |
| 2X6AWG | 18.6 | 247 | 494 | |
| 3G6AWG | 19.9 | 370 | 672 | |
| 4G6AWG | 22.4 | 493 | 882 | |
| 5G6AWG | 24.9 | 616 | 1148 | |
| 2X4AWG | 22.0 | 405 | 741 | |
| 3G4AWG | 23.7 | 608 | 1027 | |
| 4G4AWG | 26.1 | 810 | 1317 | |
| 5G4AWG | 29.4 | 1013 | 1738 | |
| 2X2AWG | 26.0 | 599 | 1065 | |
| 3G2AWG | 27.6 | 898 | 1447 | |
| 4G2AWG | 31.2 | 1198 | 1922 | |
| 5G2AWG | 34.6 | 1497 | 2480 |
