| 序号 | 芯数 X 标称截面AWG | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 2X20AWG | 5.8 | 9.9 | 42 |
| 2 | 3G20AWG | 6.1 | 14.8 | 52 |
| 3 | 4G20AWG | 6.9 | 19.7 | 67 |
| 4 | 5G20AWG | 7.4 | 24.7 | 80 |
| 5 | 6G20AWG | 8.3 | 29.6 | 96 |
| 6 | 7G20AWG | 8.9 | 34.6 | 110 |
| 7 | 8G20AWG | 9.8 | 39.5 | 138 |
| 8 | 10G20AWG | 10.7 | 49.4 | 153 |
| 9 | 12G20AWG | 11.0 | 59.2 | 172 |
| 10 | 16G20AWG | 12.3 | 79.0 | 223 |
| 11 | 18G20AWG | 13.2 | 88.8 | 253 |
| 12 | 20G20AWG | 13.8 | 98.7 | 278 |
| 13 | 24G20AWG | 15.4 | 118.5 | 346 |
| 14 | 30G20AWG | 16.5 | 148.1 | 399 |
| 15 | 36G20AWG | 17.9 | 177.7 | 475 |
| 16 | 40G20AWG | 19.3 | 197.4 | 544 |
| 17 | 2X18AWG | 6.3 | 15.6 | 52 |
| 18 | 3G18AWG | 6.8 | 23.4 | 69 |
| 19 | 4G18AWG | 7.7 | 31.1 | 89 |
| 20 | 5G18AWG | 8.3 | 38.9 | 106 |
| 21 | 6G18AWG | 9.2 | 46.7 | 127 |
| 22 | 7G18AWG | 9.9 | 54.5 | 152 |
| 23 | 8G18AWG | 10.9 | 62.3 | 182 |
| 24 | 10G18AWG | 11.9 | 77.8 | 203 |
| 25 | 12G18AWG | 12.2 | 93.4 | 229 |
| 26 | 16G18AWG | 13.7 | 124.5 | 297 |
| 27 | 18G18AWG | 14.4 | 140.1 | 329 |
| 28 | 20G18AWG | 15.3 | 155.7 | 376 |
| 29 | 24G18AWG | 17.1 | 186.8 | 460 |
| 30 | 30G18AWG | 18.3 | 233.5 | 532 |
| 31 | 36G18AWG | 19.8 | 280.2 | 634 |
| 32 | 40G18AWG | 21.4 | 311.3 | 723 |
| 33 | 2X16AWG | 7.1 | 24.1 | 69 |
| 34 | 3G16AWG | 7.5 | 36.2 | 89 |
| 35 | 4G16AWG | 8.4 | 48.2 | 115 |
| 36 | 5G16AWG | 9.3 | 60.3 | 143 |
| 37 | 6G16AWG | 10.3 | 72.3 | 170 |
| 38 | 7G16AWG | 11.3 | 84.4 | 209 |
| 39 | 8G16AWG | 12.4 | 96.4 | 248 |
| 40 | 10G16AWG | 13.1 | 120.5 | 265 |
| 41 | 12G16AWG | 13.7 | 144.6 | 308 |
| 42 | 16G16AWG | 15.1 | 192.8 | 393 |
| 43 | 18G16AWG | 16.1 | 216.9 | 445 |
| 44 | 20G16AWG | 17.1 | 241.0 | 507 |
| 45 | 25G16AWG | 19.1 | 301.3 | 611 |
| 46 | 36G16AWG | 22.3 | 433.8 | 868 |
| 47 | 2X14AWG | 8.1 | 38.0 | 95 |
| 48 | 3G14AWG | 8.6 | 57.0 | 123 |
| 49 | 4G14AWG | 9.5 | 76.0 | 160 |
| 50 | 5G14AWG | 10.6 | 95.0 | 198 |
| 51 | 6G14AWG | 11.7 | 114.0 | 235 |
| 52 | 7G14AWG | 12.8 | 133.0 | 289 |
| 53 | 8G14AWG | 13.9 | 152.0 | 334 |
| 54 | 10G14AWG | 15.1 | 190.0 | 376 |
| 55 | 12G14AWG | 15.6 | 228.0 | 430 |
| 56 | 16G14AWG | 17.4 | 304.0 | 561 |
| 57 | 18G14AWG | 18.5 | 342.1 | 633 |
| 58 | 20G14AWG | 19.6 | 380.1 | 718 |
| 59 | 24G14AWG | 22.1 | 456.1 | 885 |
| 60 | 2X12AWG | 9.1 | 60.3 | 128 |
| 61 | 3G12AWG | 9.8 | 90.4 | 174 |
| 62 | 4G12AWG | 11.0 | 120.5 | 226 |
| 63 | 5G12AWG | 12.2 | 150.6 | 280 |
| 64 | 6G12AWG | 13.4 | 180.8 | 333 |
| 65 | 7G12AWG | 14.7 | 210.9 | 407 |
| 66 | 8G12AWG | 16.1 | 241.0 | 479 |
| 67 | 10G12AWG | 17.5 | 301.3 | 542 |
| 68 | 12G12AWG | 18.0 | 361.5 | 622 |
| 69 | 16G12AWG | 20.2 | 482.0 | 812 |
| 70 | 2X10AWG | 11.4 | 97.3 | 194 |
| 71 | 3G10AWG | 12.3 | 146.0 | 264 |
| 72 | 4G10AWG | 13.6 | 194.7 | 342 |
| 73 | 5G10AWG | 15.1 | 243.3 | 440 |
| 74 | 2X8AWG | 14.4 | 155.7 | 308 |
| 75 | 3G8AWG | 15.4 | 233.6 | 419 |
| 76 | 4G8AWG | 17.0 | 311.5 | 534 |
| 77 | 5G8AWG | 18.7 | 389.3 | 687 |
| 78 | 2X6AWG | 18.6 | 246.6 | 494 |
| 79 | 3G6AWG | 19.9 | 369.9 | 672 |
| 80 | 4G6AWG | 22.4 | 493.1 | 882 |
| 81 | 5G6AWG | 24.9 | 616.4 | 1148 |
| 82 | 2X4AWG | 22.0 | 405.1 | 741 |
| 83 | 3G4AWG | 23.7 | 607.6 | 1027 |
| 84 | 4G4AWG | 26.1 | 810.2 | 1317 |
| 85 | 5G4AWG | 29.4 | 1012.7 | 1738 |
| 86 | 2X2AWG | 26.0 | 598.8 | 1065 |
| 87 | 3G2AWG | 27.6 | 898.2 | 1447 |
| 88 | 4G2AWG | 31.2 | 1197.6 | 1922 |
| 89 | 5G2AWG | 34.6 | 1497.1 | 2480 |
