| 物料编号 | 规格 | 导体根数 | 导体直径mm | 绝缘厚度mm | 尼龙厚度mm | 绝缘外径mm | 电缆重量kg/km |
| 18AWG | 17 | 0.254 | 0.38 | 0.10 | 2.2 | 12 | |
| 16AWG | 26 | 0.254 | 0.38 | 0.10 | 2.5 | 17 | |
| 14AWG | 19 | 0.37 | 0.38 | 0.10 | 2.9 | 24 | |
| 12AWG | 19 | 0.47 | 0.38 | 0.10 | 3.4 | 37 | |
| 10AWG | 19 | 0.59 | 0.51 | 0.10 | 4.3 | 58 | |
| 8AWG | 19 | 0.73 | 0.76 | 0.13 | 5.5 | 92 | |
| 6AWG | 19 | 0.92 | 0.76 | 0.13 | 6.5 | 138 | |
| 4AWG | 19 | 1.19 | 1.02 | 0.15 | 8.4 | 232 | |
| 2AWG | 19 | 1.5 | 1.02 | 0.15 | 9.9 | 354 | |
| 1AWG | 19 | 1.68 | 1.27 | 0.18 | 11.4 | 451 | |
| 1/0AWG | 19 | 1.84 | 1.27 | 0.18 | 12.2 | 533 | |
| 2/0AWG | 19 | 2.12 | 1.27 | 0.18 | 13.6 | 693 | |
| 3/0AWG | 19 | 2.39 | 1.27 | 0.18 | 15.0 | 868 | |
| 4/0AWG | 19 | 2.68 | 1.27 | 0.18 | 16.4 | 1077 | |
| 250Kcmil | 37 | 2.08 | 1.52 | 0.20 | 18.1 | 1277 | |
| 300Kcmil | 37 | 2.28 | 1.52 | 0.20 | 19.5 | 1518 | |
| 350Kcmil | 37 | 2.48 | 1.52 | 0.20 | 20.9 | 1781 | |
| 400Kcmil | 37 | 2.64 | 1.52 | 0.20 | 22.0 | 2006 | |
| 500Kcmil | 37 | 2.95 | 1.52 | 0.20 | 24.2 | 2482 |
