应用范围：
| 编号 | 规格 | 导体根数 | 导体直径mm | 绝缘厚度mm | 绝缘外径mm | 电缆重量kg/km |
| 1 | 14AWG | 7 | 0.62 | 0.76 | 3.5 | 30 |
| 2 | 12AWG | 7 | 0.78 | 0.76 | 3.9 | 44 |
| 3 | 10AWG | 7 | 0.98 | 0.76 | 4.6 | 65 |
| 4 | 8AWG | 7 | 1.23 | 1.14 | 6.2 | 107 |
| 5 | 6AWG | 7 | 1.56 | 1.14 | 7.1 | 160 |
| 6 | 4AWG | 7 | 1.96 | 1.14 | 8.5 | 238 |
| 7 | 2AWG | 7 | 2.47 | 1.14 | 10.0 | 370 |
| 8 | 1AWG | 19 | 1.69 | 1.4 | 11.5 | 483 |
| 9 | 1/0AWG | 19 | 1.89 | 1.4 | 12.6 | 574 |
| 10 | 2/0AWG | 19 | 2.13 | 1.4 | 13.7 | 710 |
| 11 | 3/0AWG | 19 | 2.39 | 1.4 | 15.0 | 917 |
| 12 | 4/0AWG | 19 | 2.68 | 1.4 | 16.5 | 1093 |
| 13 | 250Kcmil | 37 | 2.07 | 1.65 | 18.3 | 1296 |
| 14 | 300Kcmil | 37 | 2.27 | 1.65 | 19.7 | 1537 |
| 15 | 350Kcmil | 37 | 2.45 | 1.65 | 21.0 | 1777 |
| 16 | 400Kcmil | 37 | 2.62 | 1.65 | 22.2 | 2108 |
| 17 | 450Kcmil | 37 | 2.78 | 1.65 | 23.3 | 2358 |
| 18 | 500Kcmil | 37 | 2.93 | 1.65 | 24.3 | 2490 |
