应用范围：
| 物料编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 2X4.0mm² | 12.0 | 75.4 | 197 |
| 2 | 3G4.0mm² | 12.7 | 113.1 | 254 |
| 3 | 4G4.0mm² | 14.1 | 150.8 | 326 |
| 4 | 5G4.0mm² | 15.6 | 188.5 | 419 |
| 5 | 2X6.0mm² | 13.8 | 113.1 | 271 |
| 6 | 3G6.0mm² | 14.6 | 169.7 | 353 |
| 7 | 4G6.0mm² | 16.0 | 226.3 | 444 |
| 8 | 5G6.0mm² | 17.6 | 282.8 | 571 |
| 9 | 2X10mm² | 17.0 | 188.5 | 415 |
| 10 | 3G10mm² | 18.0 | 282.8 | 549 |
| 11 | 4G10mm² | 20.4 | 377.1 | 729 |
| 12 | 5G10mm² | 22.7 | 471.4 | 947 |
| 13 | 2X16mm² | 20.2 | 302.0 | 616 |
| 14 | 3G16mm² | 21.4 | 453.0 | 819 |
| 15 | 4G16mm² | 24.0 | 604.0 | 1071 |
| 16 | 5G16mm² | 26.6 | 755.0 | 1387 |
| 17 | 2X25mm² | 25.0 | 472.2 | 946 |
| 18 | 3G25mm² | 26.5 | 708.3 | 1263 |
| 19 | 4G25mm² | 30.0 | 944.4 | 1677 |
| 20 | 5G25mm² | 33.6 | 1180.5 | 2199 |
| 21 | 2X35mm² | 28.0 | 660.7 | 1239 |
| 22 | 3G35mm² | 30.1 | 991.1 | 1700 |
| 23 | 4G35mm² | 33.9 | 1321.5 | 2246 |
| 24 | 5G35mm² | 37.5 | 1651.9 | 2887 |
