| 编号 | 规格 | 导体根数 | 导体直径mm | 绝缘厚度mm | 绝缘外径mm | 电缆重量kg/km |
| 1 | 4mm² | 82 | 0.25 | 1.2 | 5.1 | 61 |
| 2 | 6mm² | 122 | 0.25 | 1.2 | 5.9 | 84 |
| 3 | 10mm² | 204 | 0.25 | 1.4 | 7.4 | 136 |
| 4 | 16mm² | 326 | 0.25 | 1.4 | 8.6 | 200 |
| 5 | 25mm² | 510 | 0.25 | 1.6 | 10.5 | 305 |
| 6 | 35mm² | 713 | 0.25 | 1.6 | 11.9 | 409 |
| 7 | 50mm² | 1018 | 0.25 | 1.6 | 13.5 | 560 |
| 8 | 70mm² | 1426 | 0.25 | 1.6 | 15.4 | 760 |
| 9 | 95mm² | 1935 | 0.25 | 1.8 | 17.8 | 1024 |
| 10 | 120mm² | 2442 | 0.25 | 1.8 | 19.6 | 1273 |
| 11 | 150mm² | 3055 | 0.25 | 2.0 | 21.9 | 1594 |
| 12 | 185mm² | 1472 | 0.40 | 2.0 | 23.9 | 1936 |
| 13 | 240mm² | 1910 | 0.40 | 2.2 | 27.0 | 2498 |
