应用范围：
| 编号 | 规格 | 导体根数 | 导体直径mm | 绝缘外径mm | 成品外径mm | 导体最大电阻Ω/km |
| 1 | 1.5mm² | 30 | 0.25 | 2.65 | 3.70 | 13.7 |
| 2 | 2.5mm² | 49 | 0.25 | 3.10 | 4.20 | 8.21 |
| 3 | 4.0mm² | 56 | 0.285 | 3.55 | 4.60 | 5.09 |
| 4 | 6.0mm² | 84 | 0.285 | 4.15 | 5.20 | 3.39 |
| 5 | 10mm² | 77 | 0.40 | 5.15 | 6.30 | 1.95 |
| 6 | 16mm² | 126 | 0.40 | 6.70 | 8.20 | 1.24 |
| 7 | 25mm² | 196 | 0.40 | 8.10 | 10.00 | 0.795 |
| 8 | 35mm² | 276 | 0.40 | 9.50 | 11.50 | 0.565 |
| 双并 | ||||||
| 1 | 2*1.5mm² | 30 | 0.25 | 2.65 | 3.70*7.60 | 13.7 |
| 2 | 2*2.5mm² | 49 | 0.25 | 3.10 | 4.20*8.60 | 8.21 |
| 3 | 2*4.0mm² | 56 | 0.285 | 3.55 | 4.60*9.40 | 5.09 |
| 4 | 2*6.0mm² | 84 | 0.285 | 4.15 | 5.20*10.60 | 3.39 |
| 5 | 2*10mm² | 77 | 0.40 | 5.15 | 6.30*12.80 | 1.95 |
| 6 | 2*16mm² | 126 | 0.40 | 6.70 | 8.20*16.70 | 1.24 |
| 7 | 2*25mm² | 196 | 0.40 | 8.10 | 10.00*20.30 | 0.795 |
| 8 | 2*35mm² | 276 | 0.40 | 9.50 | 11.50*23.30 | 0.565 |
